Eastwood Handheld Metal Hole Punch Tool

Quickly pierce metals while leaving perfectly round holes behind with the Eastwood Metal Hand Punching Tool. This 17-piece heavy-duty power punch kit provides over 2,400 pounds of punching power for accurate holes. It’s a fast and clean way to start holes for drilling or form them for rivets, bolts and other fasteners. You can also use them to remove damaged rivets or, form more visible points for a metal shear.

This metal hand punch tool works on steel, aluminum and brass up to 16 gauge and has a 5/8-inch jaw opening. It comes with six sizes of punch and die sets, and by using the adjustable work stop, you can form holes up to 3.25 inches inward from the edge.

Specifications

1.2 Ton Max. Pressure
3.25" Throat Depth
5/8" Jaw Opening

Mild Steel Maximum Material Thickness:
1/8" up to 16 gauge
3/16" and 1/4" up to 18 Gauge
5/16" and 3/8" up to 20 Gauge
7/16" up to 22 Gauge

Contents

Hand Punch with installed adjustable Work Stop
1/8 Inch Punch and Die
3/16 Inch Punch and Die
1/4 Inch Punch and Die
5/16 Inch Punch and Die
3/8 Inch Punch and Die
7/16 Inch Punch and Die Key
