Packlist: LT-298 Cb Radio x 1 Microphone x 1 Mounting Bracket x 1 Mounting Hardware x 1 MicroPhone Holder x 1 User Manual x 1
LUITON LT-298 CB Radio is a compact and affordable full 40 channel CB radio featuring CB with an easy-to-read large Led Digital display.
LUITON 40 Channel Compact Mobile CB Radio
LUITON Cb Radio
Feature:
Stable quality as Uniden PRO520XL; 4 W RF power 40 AM channels Channel 9 Mode AM switch With adjustable ASQ RSSI indication (4-digit LED indication) 2 Digit channel indication RF gain control Volume with power ON/OFF control TX/RX LED indication Up/Down microphone Front microphone plug Jack for external speaker Manual Squelch ANT Connector FREQ. expanding (A,B,C,D,E,F,POLAND and NZ band)
Transmitter:
System : CPU controlled P.L.L. synthesizer Maximum RF power : 4W -10W Modulation : 85% to 90% (AM) 2KHz ±0.2 KHz (FM) ANT impedance : 50 ohm unbalanced Current drain : 1500mA (at no modulation)
LT-298
Technical Indicators:
Channels : 40 AM
Frequency range : 26.960 – 27.400MHz
Frequency control : P.L.L.
Frequency Tolerance : ±0.005%
Operating temperature : -20°/+55°C
DC input voltage : 12-24V DC
Size : 115 (L) x 38 (A) x 150 (P) mm
Weight : 0.8 kg
Receiver:
System : CPU controlled Double conversion super IF : 1° 10.7 MHz / 2° 450 KHz Sensitivity : -120dBm for 12dB SINAD (FM) -107dBm for 12dB SINAD (AM) Audio output : @10% THD 2.5W at 8 ohm Audio distortion : <8% at 1 KHz Image rejection : 65dB Adjacent channel : 85dB Signal ise ratio : 45dB Current drain : 220mA (stand-by)
