B&C 15" 1400 Watt Subwoofer with 4" Coil Ceramic - 15PZB100-8

* 1400 w continuous program power capacity
* 100 mm (4 in) copper voice coil
* 40 - 2000 hz response
* 97 db sensitivity
* double silicone spider w/optimized compliance
* nominal diameter 380 (15) mm (in)
* nominal impedance (1) 8 ohm
* minimum impedence 6.4 ohm
* nominal power handling (2) 700 w
* continuous power handling (3) 1400 w
* sensitivity (1w/1m) (4) 97 db
* frequency range 40 - 2000 hz
* voice coil diameter 100 (4) mm (in)
* winding material copper
* former material glass fibre
* winding depth 21 (0.83) mm (in)
* magnetic gap depth 9 (0.35) mm (in)
* flux density 1.15 t
* thiele & small parameters
* fs 39 hz
* re 5.2 ohm
* qes 0.3
* qms 6.5
* qts 0.29
* vas 110 (3.8) dm3 (ft3)
* sd 855 (132.5) cm2 (in2)
* eta zero 2.1 %
* xmax +/- 8 mm
* xvar +/- 6.5 mm
* mms 154 g
* bl 28.8 txm
* le 2 mh

mounting & shipping info
* overall diameter 393 mm (15.5 in)
* bolt circle diameter 374 mm (16.7 in)
* baffle cutout diameter 354 mm (13.9 in)
* depth 174 mm (6.85 in)
* flange & gasket thickness 16 mm (5/8 in)
* net weight 11.8 kg (26 lb)
* shipping weight 13.1 kg (28.8 lb)
* shipping box 450x450x200 mm; (17.7x17.7x7.9 in)

(1) for different impedances, please ask.
(2) 2 hours test made w/continuous pink noise signal (6 db crest factor).
power calculated on rated minimum impedance.
(3) power on continuous program is defined as 3 db greater than the nominal rating.
(4) applied rms voltage is set to 2.83v for 8 ohms nominal impedance.
