"Good to go" for any DIY IOT project, qBodyMini Arduino MKR Compatible Interface Board Kit is the part of the newest Interface Board Kits line designed to help hobbyists, makers and all DIYers to build IOT POCs and making HW prototyping easily:
IOT device peripheral integrated : External power DC/DC, temperature and motion sensors, Real-Time Clock IC , Serial Flash, GPIOs and 1-Wire schematic;
Unique interface switching system : All external interfaces and most of IOT GPIOs could be easily switched to bring functionality required;
Rich set of interface options : Two terminal blocks, 4-pin JST I2C&Power, qJam and low profile 0.1" Adafruit Feather Compatible interface connectors and RTC holder;
Some room for prototyping : Proto holes grid across whole PCB space for DIP components installation and wiring;
Environmental ready : Developed to be perfectly fit and mounted inside qBoxMini Collection Enclosures for indoor and outdoor DIY IOT projects.
Each qBodyMini Arduino MKR Compatible PCB kit consists of high-quality double sided PCB with electronic components and set of connectors installed and 3,5mm terminal plugs.
PCB has enough space to keep one Arduino MKR Compatible (AMC) IOT board, power supply (DC/DC), OLED display and sensor modules, as example, using plain grid proto holes.
There are two pluggable 3,5mm terminal blocks to be used for external power or/and GPIO lines. Board has several options for I2C connection : one qJam and one 4-pin JST (I2C&Power) connectors populated on PCB. And still several DIP 0.1" I2C interface connectors could be placed at PCB.
PCB could be easily placed inside IP65 waterproof qBoxMini enclosure : just remove by plier PCB corners, mount PCB inside an enclosure and secure it by two 3,5mm self-tapping screws.
The PCB of qBodyMini Arduino MKR Compatible PCB Kit is used as the same PCB module as used for qBoxMini BoD Enclosure Kits.
Using qBodyMini Arduino MKR Compatible PCB kit the variety of DIY IOT prototyping and POC projects could be done.
What's included:
- qBodyMini Arduino MKR Compatible Interface Board;
- Two terminal block plugs.
Schematic: qBodyMini Arduino MKR Compatible Interface Board Kit schematic.
Source Code:
- IoTBotsCom_qBox : Arduino Compatible IOT FrameWork to be run on Arduino MKR Compatible and Adadfruit Feather Compatible IOT boards;
- IoTBotsCom_qFWK : Demo Library to
