Pioneer GM-ME600X6 Marine 6-Channel Class-D amplifier, system multi-configuration, SAE J1171 certified + ABYC / NMMA compliant

The Pioneer GM-ME600X6 is a Class-D 6-channel amplifier that can provide 100 watts RMS per channel into a 4Ω or 2Ω load and is designed for the marine environment. The marine amp carries an IP67 rating and is SAE J1171 certified for external ignition protection of marine electrical devices. All connection terminals are ABYC/NMMA compliant for marine use.

Amplifier Topology -
The GM-ME600X6 is a Class-D amplifier that features advanced conformal-coated PCBs for protection from moisture, dust, corrosion, and contamination. The amplifier's unique design allows it to operate in either Normal or High-Power mode (switchable for each set of channels), depending on the wattage rating of your connected speakers.

Speaker Level Input -
Three sets of RCA input jacks can be used for preamp level or speaker level input signals. If connecting the source unit's speaker wire to the input jacks, use the included Speaker-to-RCA adapters. When using a speaker level input signal, it may not be necessary to connect a remote turn-on lead because of the amplifier's signal sensing function.

Protection Control System (PCS) -
The GM-ME600X6 features Pioneer's Protection Control System (PCS) that uses a microprocessor to provide thermal protection as well as controlled current and voltage protection.

Specifications -
• RMS Power Output (Watts x Channels): 100 x 6
• Frequency Response at Rated RMS Power: 20Hz-20k Hz
• THD at Rated RMS Power: 1%
• Signal to Noise Ratio: 95 dB
• Input Voltage: 14.4v
• Power at 2 Ohms (Watts x Channels): 100 x 6
• Bridged Power (Watts x Channels): 200 x 3
• Minimum Impedance Bridged: 4
• Minimum Impedance Unbridged: 2
