Ziuscore ANENG 2000mΩ 1999 Counts Digital Megohmmeter Portable Insulation Resistance Meter Battery Powered Tester Electrician Supplies Red

Description:
Wide application: This digital megohmmeter is often used in an electric motor, cable, machine, and other for things.
Useful tool: This digital resistance tester can test the insulation resistance and can also turn a 12V voltage into a 250V/500V/1000V DC voltage.
Convenient to use: This ohm measuring device features a backlight design, so you can easily read it in the dark.
Practical tool: This digital megohmmeter is portable, has a wide measurement range, and other features.
Easy to operate: This portable megohmmeter features a button operation and has a knob to adjust the output voltage.
Specification:
Material: ABS plastic.
Color: Red, green.
Size(LxWxH): Approx. 165x120x57mm/6.50x4.72x2.24 inch.
Battery: 8x AA batteries(Not included).
Maximum display: 1999.
Output voltage: 250V/500V/1000V ± 10%.
Test current: 250V (R=250K Ω)1mA ± 10%, 500V(R=500kΩ)1mA ±10%, 1000V(R=1MΩ)1mA ±10%.
Insulation resistance: 250V: 0.1MΩ-20mΩ±(4%±2), 500V: 0.1MΩ-50MΩ±(4%±2), 1000V: 0.1MΩ-100MΩ±(4%±2), 250V: 20MΩ-500MΩ±(4%±2), 500V: 50MΩ-1000MΩ±(4%±2), 1000V: 100MΩ-2000MΩ±(4%±2).
Short circuit current: <1.6mA.
Median resistance: 250V/500V: 2mΩ, 1000V: 5MΩ.
for AC voltage: 750V±(1%+6).
Note:
There might be a bit of color distortions due to different computer resolutions.
There might be a slight error due to different hand measurements.
Package Includes:
1 Piece Digital Megohmmeter(with 2 Pieces Test Lines, 2 Pieces Clips, 1 Piece User Manual).
