Ubiquiti Networks NanoStation Wireless Access Point AirMax - LOCOM5(US)

Featuring a panel antenna and dual-polarity performance; the NanoStationM is ideal for Point-to-MultiPoint (PtMP) applications requiring high-performance CPE devices with a sleek form factor.

Compact CPE Design

The NanoStation M features the CPE design that expanded the global Wireless ISP industry.

Plug and Play Installation

The NanoStation M requires no tools for assembly; only a single wrench is required for pole-mounting.

Versatile Application Use

The NanoStation M can be deployed for Point-to-Point (PtP) bridging; wireless connectivity to a video surveillance system; or use as an air MAX CPE.

Dual Ethernet Connectivity

With software-enabled PoE output; the secondary Ethernet port can power an external device; such as a PoE security camera; for seamless IP video integration.

Powerful airOS Features

Ubiquiti's versatile airOS firmware technology enables high-performance; outdoor multi-point networking. airOS provides features such as wireless settings; bridge or routing configuration and system management services.

Advanced Software Technology

Ubiquiti's air MAX technology is proven in millions of deployments worldwide; exhibiting outstanding performance in outdoor environments. The TDMA air MAX protocol enables unprecedented scalability; high throughput and low latency in unlicensed; multipoint networks.

Window/Wall Mounting Kit

Use the NanoStation Mount to quickly mount the NanoStationM on a window or wall. 180 degree vertical or horizontal adjustment allows for custom positioning.

Wall/Pole Mounting Kit

The Universal Arm Bracket is designed for convenient wall or pole mounting of the NanoStation M. 90 degree tilt adjustment allows for easy positioning.

Product Features:

• Cost-effective; high-performance
• Compact and versatile design
• Powerful integrated antenna
• Works with any suitable antenna
• Ubiquiti AirOS software
• External status LEDs
• Power over Ethernet

Specifications:

• Power Supply (PoE): 24V; 0.5A
• Max. Power Consumption 5.5W: 5.5W
• Power Method: Passive PoE (Pairs 4; 5+; 7; 8 Return)
• Operating Frequency: Worldwide: 5170-5875 MHz
• US: 5725-5850 MHz
• USA DFS: 5250-5850 MHz
• Gain: 13 dBi
• Networking Interface: (1) 10/100 Ethernet Port
• Processor Specs: Atheros MIPS 24Kc; 400 MHz
• Memory: 64 MB DDR2; 8 MB Flash
• Frequency: 5 GHz
• Cross-pol Isolation: 20 dB Minimum
• Max. VSWR: 1.4:1
• Beamwidth: 45 degree (H-pol) / 45 degree (V-pol) / 45 degree (Elevation)
• Polarization: Dual Linear
• Enclosure: Outdoor UV Stabilized Plastic
• Mounting: Pole-Mount (Kit Included)
• Operating Temperature: -30 to 75 degree C (-22 to 167 degree F)
• Operating Humidity: 5 to 95% Noncondensing
• Wireless Approvals: FCC Part 15.247; IC RS210; CE
• RoHS Compliance: Yes
• Shock & Vibration: ETSI300-019-1.4
• Dimensions: 161 x 31 x 80 mm (6.31 x 1.22 x 3.15")
• Weight: 180 g (6.35 oz.)
