Sz02 Smart Digital Multimeter 6000 Counting Rms Automatic Capacitance Meter Red

(No ratings yet)

Key item features

[COMPREHENSIVE MEASUREMENT FUNCTIONS] This digital multimeter offers a wide range of measurement capabilities including voltage, current, resistance, continuity, diode testing, frequency detection, and non-contact voltage detection, making it a tool for both professionals and DIY enthusiasts.
[USER-FRIENDLY DESIGN] Featuring a 9999 count LCD display with backlight, this multimeter s clear readings in any lighting condition. The automatic range feature simplifies usage for users of all skill levels.
[INNOVATIVE STRIP LIGHTING] The unique strip lighting on both sides of the screen changes with electric field strength, providing an intuitive visual indication that enhances usability and safety during measurements.
[AUTOMATIC SHUTDOWN FOR EFFICIENCY] To conserve battery life, this multimeter automatically shuts down after 15 minutes of inactivity. It also includes a current sensing alarm to you during measurements.
[SIZING REMINDER] Please check your size chart to proper fit before purchasing.

Specs

Multimeter type
Digital
Features
Automatic Shut Off
Volts
9.99 V
Brand
JUANCHENG
Display
LCD
Power type
Battery

Current price is Now $18.39

You save $4.12

was $22.51

Price when purchased online

Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $3.00

2-Year Plan - $2.00

How do you want your item?

Ships to

Arrives between Jul 14 - Jul 20

Shipping fee $7.99

Sold and shipped by juancheng

3.625 stars out of 5, based on 96 seller reviews(3.6)

Free 30-day returns

More seller options (1)

Starting from $16.99

About this item

Product details

Features:

1. Easy to use: This product is a battery-powered automatic range digital multimeter with true effective value.

2. Digital display: The instrument has 9999 count display, LCD display, backlight display, and clear readings.

3. Strip lighting: The strip lighting on both sides of the screen will change synchronously with the electric field strength. LED lights are used and are not affected by light.

4. Multimeter: Voltage, current, resistance, continuity, diode, frequency and non-contact voltage detection can be used.

5. Automatic shutdown: The multimeter automatically shuts down after 15 minutes. Current sensing alarm function, wired measurement alarm.

Specifications:

Part name: Digital multimeter

Material: ABS

Size: 127x67x29.2mm/5x2.64x1.15in

Color: Orange, Red

Display type: Digital display

Is it a smart device: No

Maximum display value: 9999 counts

Auto shutdown time: 15 minutes

Sampling time: about 3 times/second

Model: SZ02

AC current: 999.9mA/10A

DC current : 999.9mA/10A

DC voltage: 600.0mV/9.999V/99.99V/999.9V

AC voltage: 600.0mV/9.999V/99.99V/999.9V

Line continuity test: 1Ω

Resistance: 999.9Ω/9.999kΩ/99.99kΩ/999.9kΩ/9.999MΩ/99.99MΩ

Diode test: 1V

Capacitance: 9.999nF/999.9nF/9.999uF/99.99uF/999.9uF/9.999mF/99.999mF

NCV: Yes

Temperature: -40 - 1000℃/-40 - 1832℉

Frequency: 100Hz/1000Hz

Power: 2 AAA batteries (not included)

Package Contents:

A: 1 multimeter + 2 test leads + 1 manual (basic version) - red

B: 1 multimeter + 2 test leads + 1*temperature line + 1 manual (high-end version) - red

C: 1 multimeter + 2 test leads + 1 manual (basic version) - orange

D: 1 multimeter + 2 test leads + 1*temperature line + 1 This manual (high-end version) - Orange

Note:

Due to different monitors and lighting effects, the actual color of the item may be slightly different from the color shown on the picture. Thank you!

Please allow 1-2 cm measurement deviation due to manual measurement.

[COMPREHENSIVE MEASUREMENT FUNCTIONS] This digital multimeter offers a wide range of measurement capabilities including voltage, current, resistance, continuity, diode testing, frequency detection, and non-contact voltage detection, making it a tool for both professionals and DIY enthusiasts.
[USER-FRIENDLY DESIGN] Featuring a 9999 count LCD display with backlight, this multimeter s clear readings in any lighting condition. The automatic range feature simplifies usage for users of all skill levels.
[INNOVATIVE STRIP LIGHTING] The unique strip lighting on both sides of the screen changes with electric field strength, providing an intuitive visual indication that enhances usability and safety during measurements.
[AUTOMATIC SHUTDOWN FOR EFFICIENCY] To conserve battery life, this multimeter automatically shuts down after 15 minutes of inactivity. It also includes a current sensing alarm to you during measurements.
[SIZING REMINDER] Please check your size chart to proper fit before purchasing.
