SereneDrains 304 Stainless Steel 48 Inch Side Outlet Linear Offset Shower Drain Brushed Nickel Long Shower Drain Kit Hair Catcher Strainer Grate Cover Bathroom Floor

SereneDrains Linear Shower Drains – Offset Drain Side Outlet – Brushed Stainless Steel

Offset Side Drain: The outlet of this Linear Shower Floor Drain is on the side of the drain, not the center.
Use the Offset Outlet Linear Drain if:
- The joist is in the center of the shower opening and notching or drilling is not an option.
- The shower is set on a 4 inch or more concrete and relocation of the drain outlet is costly.
- The drain outlet already exists on the side of the shower.

Complete Set: Linear Shower Drain Channel and Grate, Stainless Steel Hair Trap, Rubber Fitting, Grate Lifting Hook and Waterproofing Membrane Sheet to place around the drain flange (not required but included).

Central vertical outlet linear drains are also available.

Available Sizes (Approximate Dimensions) -

Length 16" (400mm), Intake 10.59 sq. in.
Length 24" (600mm), Intake 15.89 sq. in.
Length 30" (762mm), Intake 19.88 sq. in.
Length 35.43" (900mm), Intake 23.56 sq. in.
Length 39.37" (1000mm), Intake 26.47 sq. in.
Length 47.25" (1200mm), Intake 23.20 sq. in.
Length 59.05" (1500mm), Intake 39.10 sq. in.

Features -

- High Quality Materials: The Linear Shower Drain is made of 16 Gauge SS304 Stainless Steel Flange and Channel.Brushed Steel Finish protects the Linear Shower Drain from corrosion & rust.
- Easy Installation: The Shower Drain doesn’t have leveling feet. This is much more stable and makes installation easy by simply allowing you to rest the Flange on the floor edge.
- Wheelchair access (ADA Compliant) & Barrier-free showers

Technical -

- Channel width: 2 3/4" (70 mm).
- Flow rate: at entrance to shower - 6.3GPM (0.4 l/s); against the wall - 9.5GPM (0.6 l/s).
- Compatible with tiles up to 10mm depth (14mm lip).
