Tripp Lite 24 Outlet 2.9kW Single-Phase 120V Basic PDU 1U PDU2430

Tripp Lite Power Distribution Unit - 120V Input/Output Rackmount.

Tripp Lite Power distribution unit has a input/output voltage rating of 120 V and frequency rating of 50/60 Hz. Power distribution unit is rack mountable and supplies equipment with continuous power from any protected UPS.

• Single phase NEMA L5-30P 4.57m 30A 120 VAC input.
• 50/60 Hz frequency.
• Outlet connector: 24 x NEMA 5-15R.
• Cord length: 15'.
• Output voltage: 120 V, Overload protection: 30 A.
• Number of power cords: 1.
• Maximum input current: 30 A, PDU input voltage 100, 120, 127 V, Voltage compatibility: 120 VAC, Power rating: 24.
• Dimensions: 1.75"(H) x 17.5"(W) x 4.5"(D).
• Outlets center to center measurement: Distance between Front outlets = 30.2mm, Distance between Rear outlets = 30.2mm, TVSS grounding: Back panel nut and bolt grounding lug.
• Style: Rackmount, vertical rackmount, wallmount/under-counter, Form factor supported: 1U rackmount, 0U vertical rackmount, wall-mount and undercounter installation supported.
• High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
• Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats.
• Supplies equipment with continuous power from any protected UPS, generator or mains input power source.
• Certifications and standards: Tested to UL60950-1 (USA) and CAN/CSA C22.2 No. 60950-1-03 (Canada), RoHS compliant.
• Weight: 3.3 lbs.

Keep your unruly power cords organized and at the ready with this Tripp Lite power distribution unit. With a 15-foot cord and a style that offers rackmount, vertical rackmount, wallmount, or under-counter mount options, this unit is ideal for any space. It will provide continuous power from any generator, main input, or protected UPS power source. The all-metal housing and included mounting accessories give this unit a rugged high-quality design ...
