Pioneer® 12,000 BTU 20.8 SEER2 Ductless Mini-Split Inverter+ Air Conditioner Heat Pump System Full Set 115V

OverviewSummary

• High Efficiency Quantum Series Inverter+ ductless mini split heat pump system
• Cooling capacity: 12,000 BTU/H with 20.8 SEER2 / 10.3 EER2 efficiency
• Heating capacity: 12,000 BTU/H with 8.7 HSPF2 / 3.13 COP2 efficiency
• Voltage: 110~120V, 60Hz, 1Ph
• High Wall Mounted Air Conditioning & Heating System
• Variable Speed DC Inverter Operation Mode
• Customizable length copper line set with flare connections
• AHRI Estimated Annual Operating Costs:
• Cooling: $79.00
• Heating: $242.00

What's Included

• Indoor Unit
• Outdoor Unit
• Wireless Remote Control
• Various Installation Kit Options Available
• Flare Connection Leak Guard Sealer
• Installation Manual
• User’s Manual
• Manufacturer Warranty

Technical InformationCertifications

Performance Data

• Power Supply: 110~120V, 60Hz, 1Ph
• Cooling Rated Capacity: 12,000 BTU/h
• Cooling Capacity Range: 4,300~12,600 BTU/h
• Cooling SEER2: 20.8 BTU/W.h
• Cooling EER2: 10.3 BTU/W.h
• Heating Rated Capacity: 12,000 BTU/h
• Heating Capacity Range: 4,000~12,500 BTU/h
• Heating HSPF2 (Region IV/V): 8.7 / 6.6 BTU/W.h
• Heating C.O.P.2 (47°F/5°F): 3.13 / 1.91 W/W
• Refrigerant Type: R410A/30
• Suitable Area: 300~450 Sq.F

Indoor Unit Data

• Model Number: WS012AMFI20HLD
• Air Flow (Turbo/Hi/Med/Lo): 341 / 309 / 206 / 176 CFM
• Sound Level (Hi/Med/Lo): 41.5 / 30.5 / 26.0 dB(A)
• Net Dimensions (WDH): 31.57 x 7.44 x 11.69 Inches
• Carton Dimensions (WDH): 34.45 x 11.22 x 14.96 Inches
• Net / Gross Weight: 20 / 25 lbs

Outdoor Unit Data

• Model Number: YN012AMFI20RPD
• Sound Level: 55.5 dB(A)
• Net Dimensions (WDH): 30.1 x 11.93 x 21.85 Inches
• Carton Dimensions (WDH): 34.8 x 13.25 x 24 Inches
• Net / Gross Weight: 62.2 / 67.7 lbs
• Breaker Needed: 20A (single-pole)

Manuals & Downloads

• Technical Brochure
• User Manual
• Installation Manual
• Service Manual
• Disassembly Guide
• AHRI Certificate
• Energy Guide
