Parts Express Speaker L-Pad Attenuator 100W Mono 1" Shaft 8 Ohm

L-pads adjust the relative volume of drivers connected to them by placing added resistance in series and parallel, keeping impedance a constant 8 ohm load. This L-pad is rated at 100 watts RMS, is designed to be used with 8 ohm loads, features a 1" shaft length, and comes with mounting hardware.

Key Features:

• Easy level adjustment without changing impedance
• Great for speaker design tweaking
• Maintains 8 ohm impedance
• Mounting hardware included

Speaker L-Pad Attenuator 100W Mono 1" Shaft 8 Ohm

L-pads adjust the relative volume of drivers connected to them by placing added resistance in series. At the same time, a counter-resistance is placed in parallel with the driver to maintain a constant impedance which allows the original crossover design to be used. L-pads are to be placed in between the amplifier and speaker, or in between the crossover and driver. This particular L-pad is rated at 100 watts RMS, is designed to be used with 8 ohm loads, features a 1" shaft length, and comes with mounting hardware and faceplate.

Dimensions: 2-1/2" diameter, 1" depth.

Note: See the Tech Drawings tab for wiring instructions.

L-Pad Instruction Diagram

Product Details

BrandParts ExpressPart Number260-265UPC844632017056Unit of MeasureEachWeight0.4158
