Black Box Gigatrue Cat. 6 Channel Utp Patch Cable - Rj-45 Male - Rj-45 Male - 10ft - Purple (evnsl648-0010)

Technical Information

Cable Type: Category 6
Cable Characteristic: Patch Cable
Cable Length: 10 ft
Connector Type on First End: RJ-45 Network - Male
Connector on First End Details: 1 x RJ-45 Network - Male
Connector Type on Second End: RJ-45 Network - Male
Connector on Second End Details: 1 x RJ-45 Network - Male
Contact Plating: Gold
Conductor: Copper
Shielding: No
Jacket Type: CM
Device Supported: Patch Panel, Wallplate, Network Device
American Wire Gauge: 24 AWG
Data Transfer Rate: 1 Gbit/s
Boot Type: Snagless
Features: Stranded, Booted, Strain Relief, Damage Resistant, Near End Cross Talk (NEXT), PoE

Physical Characteristics

Color Family: Purple
Product Color: Purple
Jacket Material: Polyvinyl Chloride (PVC)

Miscellaneous

Additional Information:

• Perfect for full broadband and baseband video
• Full Power Sum performance
• Provides full-duplex operation
• Meets balance requirements (LCL/LCTL)
• Improved attenuation provides cleaner data and video transmissions
• Attenuation: 23.6 dB at 100 MHz, 39.1 dB at 250 MHz
• Delay Skew (Maximum): 25 ns/100 m (328 ft.)
• Impedance: 100 ± 15 ohms at 100 MHz, 100 ± 22 ohms at 100-550 MHz
• Mutual Capacitance (Maximum): 56 pF/m
• NEXT: 45.0 dB at 100 MHz, 39.0 dB at 250 MHz
• PS-ACR: 32 dB (Typical) at 100 MHz
• PS-NEXT: 43.0 dB at 100 MHz, 37.0 dB at 250 MHz
• Resistance (Maximum): 9.09 Ohms/100 m (328 ft.)
• Return Loss: 22.5 dB at 100 MHz, 20.5 dB at 250 MHz
• Structured Return Loss: 22.5 dB at 100 MHz, 20.5 dB at 250 MHz

Applications:

• 1000BASE-T
• 100BASE-TX
• 100BASE-VG
• 155-Mbps ATM
• 100-Mbps FDDI/CDDI

Certifications & Standards:

EIA/TIA-568-B.2-1

Environmentally Friendly: Yes
Country of Origin: China

Warranty

Limited Warranty: Lifetime
