Tripp Lite Hardened Copper to Fiber Media Converter RJ45/SC MMF 10/100Mbps (n784-h01-scmm)

Interfaces/Ports

Total Number of Ports: 2
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 1
Number of SC Ports: 1
SC Port Type: Duplex

Media & Performance

Media Type Supported: Twisted Pair, Optical Fiber
Fiber Mode Supported: Multi-mode
Fiber Optic Cable Wavelength: 1310 nm
Maximum Distance Supported: 2 km

Network & Communication

Ethernet Technology: Fast Ethernet
Network Technology: 10/100Base-TX, 100Base-FX

Power Description

Power Source: AC Adapter
Power Consumption: 1.80 W
Plug/Connector Type: NEMA 1-15P

Physical Characteristics

Form Factor: Wall Mountable, DIN Rail Mountable, Desktop
Height: 0.9"
Width: 2.9"
Depth: 4.3"
Weight (Approximate): 8.43 oz

Miscellaneous

Package Contents:

• N784-H01-SCMM Transceiver/Media Converter
• L-shaped Bracket
• Rubber Foot
• SC Connector Cap
• External Power Supply with NEMA 1-15P Plug (Input: 100-240VAC, 50/60 Hz, 0.5A; Output: 12VDC 1.5A)
• DIN Rail Kit
• Wall-mounting Hardware
• Quick Start Guide

Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: Taiwan
TAA Compliant: Yes

Warranty

Limited Warranty: 2 Year
