Dual Air Gap with Oil Rubbed Bronze Brass Cap for Dishwasher and Reverse Osmosis Filters (with tank) and Extra Long Thread (AG200-305, AG200-X05, AMERIGAP)
Dual Air Gap with Oil Rubbed Bronze Brass Cap for Dishwasher and Reverse Osmosis Filters (with tank) and Extra Long Thread (AG200-305, AG200-X05, AMERIGAP)
Hero image 0 of Dual Air Gap with Oil Rubbed Bronze Brass Cap for Dishwasher and Reverse Osmosis Filters (with tank) and Extra Long Thread (AG200-305, AG200-X05, AMERIGAP), 0 of 9
AirGap International

Dual Air Gap with Oil Rubbed Bronze Brass Cap for Dishwasher and Reverse Osmosis Filters (with tank) and Extra Long Thread (AG200-305, AG200-X05, AMERIGAP)

(No ratings yet)
Dual Air Gap with Oil Rubbed Bronze Brass Cap for Dishwasher and Reverse Osmosis Filters (with tank) and Extra Long Thread (AG200-305, AG200-X05, AMERIGAP)Dual Air Gap Oil Rubbed Bronze Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 305 AG200 X05 AMERIGAPDual Air Gap with Black Matte Brass Cap for Dishwasher and Reverse Osmosis Filters with tank and Extra Long Thread AG200 505 AG200 X05 AMERIGAPDual Air Gap Brushed Nickel Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 105 AG200 X05 AMERIGAPDual Air Gap Polished Chrome Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 205 AG200 X05 AMERIGAPDual Air Gap Satin Nickel Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 705 AG200 X05 AMERIGAPDual Air Gap Polished Nickel Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 605 AG200 X05 AMERIGAPDual Air Gap Brushed Bronze Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 805 AG200 X05 AMERIGAPDual Air Gap for Dishwasher and Reverse Osmosis Filters with tank and Extra Long Thread AG200 005 AG200 002 T52 RO KIT AMERIGAPDual Air Gap Brushed Stainless Steel Brass Cap Dishwasher Reverse Osmosis Filters with tank Extra Long Thread AG200 405 AG200 X05 AMERIGAP
Actual Color:Oil Rubbed Bronze Brass

Key item features

  • ❤ FLOW RATE: The AG200-305’s maximum flow rate is 11 gallons per minute (GPM). The maximum flow rate of the 1/4-inch port for the reverse osmosis (RO) filter is 1 GPM. The maximum flow rate through this air gap is the highest flow rate above which the air gap will overflow. At maximum flow rate, the air gap is dry on the outside.
  • ❤ INLET PORTS: The AG200-305 accepts a standard 5/8-inch inside diameter hose from a dishwasher and a 1/4-inch outside diameter tubing from Reverses Osmosis filter (with tank). The hose from the dishwasher slides onto the side port and is secured using stainless worm clamps (not included). The RO tubing connects to a push-in quick-connect adapter. Make sure there are no kinks in the hose and that water passes freely. This air gap is compatible with all dishwashers and RO filters.
  • ❤ OUTLET PORTS: The drainage side of the air gap connects to a 7/8-inch inside diameter hose, which routes discharge water to the side drain connection on the garbage disposal. This hose is available from Home Depot (search for “PVC Disposal Discharge Hose”). When installing this hose, make sure that there is no sagging or loops. Any sagging will create standing water and will restrict the proper draining of the air gap. Secure both ends of the hose with a 1-inch stainless steel worm clamp.
  • ❤ THREADED BODY: The AG200-305 has a body with a thread that enables air gap mounting through a standard countertop. Countertop thickness can be up to 1-3/4 to 2-1/8 inches, and it does not require any special modification to accommodate this air gap. The body of the air gap made from extra durable plastic to resists bending or deforming.
  • ❤ MOUNTING NUT: The AG200-305 has a durable mounting nut that will not strip or become loose. The multi-threaded nut can be tightened without the worry of damaging threads. This configuration provides a simple and reliable installation that prevents leaks and assures trouble-free operation after the air gap is installed.
  • ❤ DECORATIVE CAP: The AG200-305 comes with an oil rubbed bronze brass cap. The AG200-X05 offers a variety of decorative cap finishes designed to complement your kitchen sink faucet. Choose the air gap variation that best matches the color of your faucet.
  • ❤ COMPATIBILITY: Our reverse osmosis air gaps such as the AG200-305 are not compatible with reverse osmosis faucets with air gap.
Current price is $201.00
Price when purchased online
  • Free shipping
  • Free 30-day returns
