Hero image 0 of Pioneer GM-ME600X6 Marine 6-Channel Class-D amplifier, system multi-configuration, SAE J1171 certified + ABYC / NMMA compliant, 0 of 6

Visit the Pioneer Store

Pioneer GM-ME600X6 Marine 6-Channel Class-D amplifier, system multi-configuration, SAE J1171 certified + ABYC / NMMA compliant

(No ratings yet)

Key item features

Robust Marine: Designed for marine environments, this Class-D 6-channel amplifier boasts an IP67 rating and is SAE J1171 certified for external ignition protection, with ABYC/NMMA compliant connection terminals.
Flexible Power: Delivers 100 watts RMS per channel into a 4 or 2 load, with a continuous power output of 6 x 75W RMS (4) or 6 x 100W RMS (2) in normal mode.
Advanced Protection: Features conformal-coated PCBs for moisture, dust, corrosion, and contamination protection, alongside Pioneer's Protection Control System (PCS) for thermal, current, and voltage safeguarding.
Versatile Connectivity: Includes three sets of RCA input jacks for preamp or speaker level signals, with automatic signal sensing and turn-on, potentially eliminating the need for a remote turn-on lead.
Configurable Output: Amplifier topology allows operation in Normal or High-Power mode, switchable for each set of channels, to match connected speaker wattage ratings.
Optimal Performance: Offers a frequency response of 20Hz-20kHz, a signal-to-noise ratio of 95 dB, and a low THD of 1% at rated RMS power.

Generated by AI

Specs

Brand
Pioneer
Rms power rating
100 W
Channels
6
Impedance
2 ohm
Peak audio power handling
200 W
Input/output type
RCA

Current price is $299.99

Price when purchased online

Free shipping
Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $29.00

4-Year Plan - $43.00

How do you want your item?

Columbus, 43215

Arrives by Fri, Feb 27

Sold and shipped by Sound of Tri-State

4.202127659574468 stars out of 5, based on 188 seller reviews(4.2)

Report an issue with this seller

Free 30-day returns

About this item

Product details

The Pioneer GM-ME600X6 is a Class-D 6-channel amplifier that can provide 100 watts RMS per channel into a 4Ω or 2Ω load and is designed for the marine environment. The marine amp carries an IP67 rating and is SAE J1171 certified for external ignition protection of marine electrical devices. All connection terminals are ABYC/NMMA compliant for marine use.

Amplifier Topology -
The GM-ME600X6 is a Class-D amplifier that features advanced conformal-coated PCBs for protection from moisture, dust, corrosion, and contamination. The amplifier's unique design allows it to operate in either Normal or High-Power mode (switchable for each set of channels), depending on the wattage rating of your connected speakers.

Speaker Level Input -
Three sets of RCA input jacks can be used for preamp level or speaker level input signals. If connecting the source unit's speaker wire to the input jacks, use the included Speaker-to-RCA adapters. When using a speaker level input signal, it may not be necessary to connect a remote turn-on lead because of the amplifier's signal sensing function.

Protection Control System (PCS) -
The GM-ME600X6 features Pioneer's Protection Control System (PCS) that uses a microprocessor to provide thermal protection as well as controlled current and voltage protection.

Specifications -
• RMS Power Output (Watts x Channels): 100 x 6
• Frequency Response at Rated RMS Power: 20Hz-20k Hz
• THD at Rated RMS Power: 1%
• Signal to Noise Ratio: 95 dB
• Input Voltage: 14.4v
• Power at 2 Ohms (Watts x Channels): 100 x 6
• Bridged Power (Watts x Channels): 200 x 3
• Minimum Impedance Bridged: 4
• Minimum Impedance Unbridged: 2

Class D amp technology

Variable low pass and High pass filter

Automatic Signal Sensing and Turn-On

Speaker Terminals Block-type

Continuous Power Output Normal Mode: 6 x 75W RMS (4Ω), 6 x 100W RMS (2Ω)
