Dc10G Engine Manual Start Controller Generator Controller Control Panel Module

Features:
* DC10G is a controller for manually starting and stopping the engine. The generator frequency, voltage, battery voltage, and cumulative working time are displayed through a 4-digit LED digital tube. It has a variety of shutdown protection and alarm indication functions, which can easily monitor the working status of the generator set. The controller can be connected to the computer via a data cable, and the parameters of the controller can be set through the software, which is convenient for matching generator sets of more specifications.
* It uses a 32-bit imported high-performance single-chip microcomputer control.
* 4-digit digital tube display, which can be switched automatically or manually.
* The vehicle start button is .
* It has a parameter setting function, and the parameters can be set through a computer connection.
* It has a variety of alarm protection functions.
* Waterproof ring is standard. The rear panel has an anti-reverse function.
* All wiring is completed through European terminals. The assembly, connection, maintenance and replacement of the equipment are very easy and convenient.

Specifications:
Part name: Engine manual start controller
Model: DC10G
Material: ABS, metal
Color: as shown
Power input: 8-33 VDC
Power consumption: 2W
Generation input: 15-300VAC, 50/60 Hz
Speed input: frequency 300Hz~10kHz
Oil valve output: 16A
Motor output: 10A
Excitation output: 80mA
Alarm output: 16A
Working temperature: -30-75℃
Storage temperature: -40-85℃
Size: approx. 78 * 78 * 72mm / 3.1 * 3.1 * 2.8in
Opening size: about 67 * 67mm / 2.6 * 2.6in
Parameter display;
Generator voltage
Generator frequency
Engine battery voltage
Unit cumulative running time
Alarm protection
Overspeed
Overfrequency
Low oil pressure
High water temperature
External parking alarm
Generator overvoltage
Charging failure

Package contents:
1 x Engine manual start controller
2 x Keys
2 x Fixing screws

Note:
1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2.Please allow slight manual measurement deviation for the data.
