Color Meter MAX Digital Portable Colorimeter Color Tester for Precise Calibration

Feature

1. Colorimeter with more accurate color measurement

Adopt the international D/8 (integrating sphere diffuse illumination, 8° observation angle), SCI illumination observation conditions, the measurement is more accurate;Using a spectral sensor to provide better spectral data than a traditional colorimeter, comparable to a spectrophotometer;You can directly see the prompt of "Pass" or "Fail" on the of the instrument, and the quality inspection is worry-free;

2. Massive color card database

Connect to the e app, create a color database, and enter the color card information of printing, coating, textile, etc.;No need to carry heavy color cards, you can use the instrument to find the closest color among multiple sets of color cards anytime and anywhere;

3. Automatic calibration

The instrument is automatically calibrated at the same time when the instrument is turned on, and the color detection can be carried out by picking up the instrument, and the data is correct;

4. Available as a stand-alone machine, with plenty of measurement and data

1.14-inch IPS display, giving you the color information you want;The instrument can store data, and open the App to synchronize data at any time;

5. Cloud database, easier to view and upload

Provide the official color card database, search at will, and use it as you like;The color information library created by the user can be uploaded to the cloud, multi-device data sharing, color processing is more convenient;Enterprise users can create and their own color card information database and color in the cloud, and share the information database and color with merchants and users through a invitation code.

Specification

Model

ColorMeter SE

ColorMeter Pro

Measurement structure

D/8, including specular reflection light (SCI)

measurement standard

CIE-Lab, E*ab, spectral curve

Spectral reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference (E*ab, E*cmc, E*94, E*00), whiteness (ASTM E313-00) , ASTM E313-73, CIE/ISO, AATCC, Hunter, TaubeBerrStensby), yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73), blackness (My, dM), stain fastness, color fastness , Tint (ASTM E313-00), color density CMYK (A, T, E, M), metamer index Milm, Munsell, hiding power, strength (dye strength, tinting power)

Spectral reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference (E*ab, E*cmc, E*94, E*00), whiteness (ASTM E313-00) , ASTM E313-73, CIE/ISO, AATCC, Hunter, TaubeBerrStensby), yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73), blackness (My, dM), stain fastness, color fastness , Tint (ASTM E313-00), color density CMYK (A, T, E, M), metamer index Milm, Munsell, hiding power, strength (dye strength, tinting power)

Lighting source

LED (full band balanced LED light source)

Measuring caliber

8mm

Wavelength interval

/

10nm

10nm

Wavelength ran

/

400-700nm

400-700nm

Measurement stability

E0.1 (measure the whiteboard 30 times every 5s)

E0.05 (measure the whiteboard 30 times every 5s)

Difference between stations

<0.4 (Measured avera value of 12 color bricks of BCRAseries)

<0.4 (Measured avera value of 12 color bricks of BCRAseries)

<0.2 (Measured avera value of 12 color bricks of BCRAseries)

measure time

1.5s

1.5s

1s

interface

USB (for charging only)

USB

USB

Light source conditions

D65

A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NBF, TL83, TL84

A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NBF, TL83, TL84

Field of view

10°

2°, 10°

2°, 10°

IPS full color (135*240, 1.14inch)

IPS full color (135*240, 1.14inch)

IPS full color (135*240, 1.14inch)

battery capacity

A single full char can continuously measure 5000 times

A single full char can continuously measure 10,000 times

A single full char can continuously measure 10,000 times

Langua

Simplified Chinese, English

Simplified Chinese, English

Simplified Chinese, English

calibration

Automatic calibration

Automatic calibration

Automatic calibration

software support

weight

About 90g

About 90g

About 90
