Ageless Iron Locaeg_Psg_238 Loch - Grey

Passage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock is not needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.

Features:

• Solid hand poured cast iron that is hand finished for a unique surface texture
• Zinc plated and powder coated for resistance to corrosion, UV weathering and scratches
• Intended for both left or right handed door configurations
• Installs on doors with 1-3/8" to 2" thickness
• Hand assembled in USA
• Coordinates well with all Ageless Iron products
• Does not comply with standards of the Americans with Disabilities Act (ADA)
• Covered under a 5 year finish and mechanical warranty

Specifications:

• Backset: 2-3/8"
• Cross Bore: 2-1/8"
• Edge Bore: 1"
• Door Thickness: 1-3/8" to 2"
• Handing: Reversible Left or Right
• Latch Faceplate: Square Corner
• Material: Iron
• Handle Height: 2-5/8"
• Handle Width: 1-5/8"
• Handle Projection: 2-7/8"

Construction and Mechanics:

• Each piece weighs between 3 and 5 pounds - made from solid, cast iron
• Every Ageless Iron product has been life tested for 12 months in Florida exposure for UV resistance and anti-corrosion
• Any wear points inside the lockset are factory lubricated for long life
• Featuring spring-assisted knobs and levers, the workmanship ensures thousands of worry free usage cycles
• Pre-mounting allows for clean and easy installation
• Floating spindle allows for minor trim alignment errors
• Two screws hold the lock trim securely to the door, providing minimal need for excess tools or expertise
• Each set ships with detailed instructions

Design Elements

• Rustic powder coated black
• Perfect for modern farmhouse to urban loft
• Sophisticated black will remain timeless season after season
