Internal resistance tester,Meter Dual Type-c Test Meter Dual Battery Test Meter 18650 Battery Display Battery Internal Battery Internal Resistance Tester Dsfen Laoshe Wenzi

Digital Display Battery Capacity Internal Resistance Tester Digital Lithium Battery Power Detector Module lithium battery Battery Test Meter Dual Type-C Interface Fan active heat dissipation, support overheating protections. Support Chinese and English interface switching, default language is Chinese. Support separate charging, separate discharging, automatic mode supports to 9 charging and discharging cycles. Adopts direct current two-wire method to test internal resistance, with high accuracy of value when battery is fully charged. Full automatic cut off charging, discharge to reach conditions automatically stop, automatic mode 1 ~ 9 times adjustable cycle. seconds), cycle times, stop discharge low voltage, working mode menu, status indication, channel indication can be seen at a glance. 2.5V, 2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, a total of 11 adjustable gear. battery battery holder using compact battery holder, suitable for flat battery measurement. product supports four-channel capacity and internal resistance measurement, each channel is independent of each other, set separately and run independently without interfering with each other.

Note:does not support charging of iron phosphate batteries.

Specifications:
Test quantity: 4-channel charging and discharging measurement
Stop discharge voltage: 2.5V, 2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, a total of 11 grades adjustable
Internal resistance measurement: support, using direct current two-wire method to test internal resistance
supplying interface: two Type-C interface
Applicable battery: meet stop discharge voltage 2.5 ~ 3.5V, 2.8V starts ~ 4.2V full battery are applicable
Item size: 150 * 103 * 36mm / 5.91 * 4.06 * 1.42in
Cycle charging and discharging: support, 1~9 cycles adjustable (only automatic mode support)
Discharge current: maximum about 1A current, not adjustable, does not support independent transformation
System language: English / Chinese switchable
Package weight: 260g / 9.17ounce
failure save: only save setting parameters, not save measurement data
Package size: 182 * 112 * 50mm / 7.07 * 4.41 * 1.97in
Discharge function: support, automatically stop when conditions are met, discharge current is not adjustable
Status prompt: support
Item weight: 200g / 7.05ounce
Operating voltage: 5VDC
Charging function: support, full automatic cut off charging (does not support charging of iron phosphate batteries)
Charging voltage: special battery charging chip control, maximum of about 1A charging, full charging voltage 4.2V
Heat dissipation mode: fan active heat dissipation
Automatic charging and discharging: support, automatic mode ends when battery is fully charged


This product support independent 4 channel internal resistance, capacity measurement. Adopts direct current two-wire method to test internal resistance, with high accuracy of value when battery is fully charged. Support separate charging, separate discharging, automatic mode supports to 9 charging and discharging cycles. battery battery holder uses compact battery holder for flathead battery measurement.

Packing List:
1 * battery Battery Capacity Internal Resistance Tester
1 * Pry Bar
