IEC Magnetic Contactor, No Auxiliary Contacts, 208V AC, 3 P, Non-Reversing, Screw XTCE050D00E

The Eaton XT IEC contactor is an IEC magnetic contactor (an electrically operated switching device) used to control power circuits in accordance with IEC standards. It is a 3-pole, non-reversing unit with a 208 V AC coil, and it includes no auxiliary contacts. It is part of the XT series (Frame D) with screw terminals and mounting options for DIN rail or panel mounting, rated for operation within the specified voltage and frequency ranges. It is rated for continuous operation at the specified current levels under normal conditions (50 A inductive; 80 A resistive). It incorporates an embedded surge suppressor and is designed to operate within the specified temperature range. - Item: IEC Magnetic Contactor; Series: XT; Type: Full voltage non-reversing contactor; Frame: D; Poles: 3; Reversing/Action: Non-Reversing; Coil voltage: 208 V AC - Auxiliary contacts: No auxiliary contacts (0 NO, 0 NC) - Mounting style: DIN Rail, Panel; Electrical connection: Screw - IP Rating: IP20; Enclosure: No Enclosure - Maximum voltage rating: 690V AC; Frequency: 60 Hz - Certifications/Standards: EN 60947; IEC 60947; UL Listed; CSA Certified; CE Marked; RoHS; UL Listed - Rated for continuous operation at the specified current levels under normal conditions: 50 A (inductive); 80 A (resistive) - Mechanical durability: 10,000,000 cycles - Embedded surge suppressor: Yes - Operating temperature: -13 Degrees F to 122 Degrees F
