OSRAM XBO 1000W/HS OFR 1000W Cinema Film Projection Lamp

OSRAM 69263 1000w OFR Xenon Discharge Lamps are intensely bright and offer excellent color rendering. Originally introduced in 1954 for cinema projection, OSRAMs innovation of XBO technology was awarded an OSCAR in 1984 for revolutionizing the film industry. Since then, the scope of applications for these high wattage XBO lamps have continued to broaden, and now they are used in spotlights for stage, studio and theatre applications, in searchlights and even in solar simulators.

The most recent innovation has been the development of XBO lamps for digital cinema projection. Designed with shorter arc gaps, these lamps provide the higher level of point-source intensity needed for today's more demanding cinema projection systems.?Key Features and Benefits
?High luminance (point source)
Color temperature approximately 6000K - simulates daylight
Continuous spectrum in the visible range
High color rendering > 95
High arc stability
DC operation
Hot restart

Abbreviation Name	XBO1000WHSOFR
Application	Cinema Film Projection, Sky Tracker / Searchlights, Follow Spots / Spotlights
Magnetic Arc Stabilization	Required
Average Luminance (cd/cm2)	60000
Base	Special Double Ended
Base Anode	SFa27-11
Base Cathode	SFcX27-8
Warranty Hours	2000
Bulb	T40,5
Class	C (gas)
Color Rendering Index (CRI)	98
Color Temperature (K)	6000
Cooling	Required
Current (A)	50
Current Control Range (A)	30-55
Diameter d (in)	1.614
Diameter d (mm)	41
Distance a (mm)	95
Electrode Gap (cold) (mm)	3.8
Family Brand Name	XBO
Hot Restart	Yes
Lamp Finish	Clear
Length l1 max. (mm)	235
Length l2 max. (mm)	205
Light Center Length - LCL (mm)	95
Luminous Area w x h (mm)	1.1 x 2.8
Luminous Flux (lm)	32000
Luminous Intensity (cd)	3000
Maximum Base Temperature °C	230
Maximum Overall Length - MOL (mm)	235
Nominal Voltage (V)	19
Nominal Wattage (W)	1000
Operating Position	s20 p20
Reflector Coating	41
Type of Current	DC
CA Prop 65	Yes
CA Prop 65 Material	Mercury
