Controller Power 180V-240V Kg316t Timing Street Light Timer Electrical

Controller Power 180V-240V Kg316t Timing Street Light Timer Electrical

Features:

brand new and high quality

Made of high quality material, durable and practical to use

Various electrical equipment can be turned on / off automatically according to the time set by the user.

The 110V timing switch has a built-in battery for storing data, while the 220V timing switch uses 1 AA battery (not included).

Repeat the procedure with the 10 on and 10 off settings with a time limit of 1 minute to 168 hours.

The setting time of the time switch can be cycled by day or week.

Timer switches are ideal for controlling street lights, neon lights, production equipment, broadcast television, and many other industrial or household appliances.

Specifications:

Optional Input Voltage: AC110V, AC220V

Contact-Voltage Rating: 180V to 240V

Switching Load Capacity: 10A

Power: <1W

On / Off Operation: 10 On and 10 Off (Manual / Automatic)

Time Limit: 1 Minute to 168 hours

Operating temperature: -20degree Celsius to 60degree Celsius

Humidity: <95%

Error: <0.5s / day

Battery (For 220V): 1 AA Battery (Not Included)

Dimensions: 120 x 74 x 51mm / 4.72 x 2.91 x 2 "(Approx.)

Explanation:

NO1 :, set the clock (current time): press and hold the "CLOCK" button, then press the "WEEK", "HOUR" and "MINUTE" buttons.

NO2: Set "1 on": Press the "TIMER" button, and "1 on" is displayed at the bottom left of the LCD display. Then press the "Hour" and "Minute" buttons to set "1 On".

NO: Set "1 off": Continue to press the "TIMER" button, "1 off" is displayed at the bottom left of the LCD. Then press the "hour" and "minute" buttons to set "1 off".

NO4: Continue to press the "TIMER" button (the LCD will display "2 ON", "2 OFF", "3 ON", "3 OFF" ... "10 ON", "10 OFF") . If you only set Need "1 on", "1 off", you must press the "Timer" button (the LCD will display "2 on", "2 off", "3 on", "3 off" ... .. "10 on "," 10 off ", then press the" RESET / RECALL "button to set all other" on "and" off "to"-:-"instead of" 00:00 "(displayed on the LCD).

NO5: After the setting is completed, press the "Clock" button to make the LCD display the current time. Or, if no button is pressed within 30 seconds, it will automatically display the current time.

NO6: When connected to a circuit, the red light indicates whether the circuit is energized, and the green light indicates whether the switch is closed.

NO7: Press the "AUTU / MANU" button to directly connect or disconnect the circuit. Press the "AUTU / MANU" button until the bottom of the LCD display shows "off", and then press the "AUTU / MANU" button again to set it back to "Auto" " .

NO8: Press the "TIMER" button and then "WEEK" to set the days of the week you need to switch to, such as (Monday, Wednesday, Friday) or (Tuesday, Thursday, Saturday) ), (Monday, Tuesday), (Wednesday) or (Thursday, Friday, Saturday), (Monday to Friday) and (Saturday, Sunday), etc.

Package Contents:

1 * Timer Switch

Note:

1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.

2.Please allow slight manual measurement deviation for the data.
