Blum 20K2b00tna Aventos Hk-S Tip-On Lift Mechanism - Grey

Features:

• Designed to work with the TIP-ON mechanism
• Well suited for small wall cabinets or cabinets above a pantry or refrigerator
• Built in BLUMOTION insures the cabinet door closes silently and effortlessly
• Two lift mechanisms are required for proper lift function
• Lift mechanisms have a power factor range of 19 to 39
• Power factor is calculated by multiplying door weight with cabinet height
• A trial application is highly recommended if calculated power factor is borderline of lift mechanism's range
• Include two (2) lift mechanism arms

Specifications:

• Cabinet Height: 7-3/8" to 24"
• Maximum Internal Cabinet Width: 72"
• Minimum Internal Cabinet Depth: 6-1/2"
• Power Factor: 19-39 (Power Factor = Cabinet Height x Door Weight)
• Opening Angle: 107°

Product Variations:

• 20K2B00TNA (This Model): TIP-ON Lift Mechanism with Power Factor from 19 to 39
• 20K2C00TNA: TIP-ON Lift Mechanism with Power Factor from 40 to 85
• 20K2E00TNA: TIP-ON Lift Mechanism with Power Factor from 86 to 177
