The Pool Supply Shop 3 HP Square Flange Full Rated Pool Pump Motor, 1.15 SF

Arriving under the specification of 3HP and 230V, this motor is a star among the mechanical devices. No more concern about pumping water as you have the apt device for life-long utilization. Cheap and reliable, as most customers expect!. Product Features: Energy-efficient switchless pool pump motor. Stainless steel shaft for corrosion protection. Sealed ball bearings. Advanced cooling system for extended motor life. Pump motor has a threaded shaft that allows for convenient and direct mounting. Additional Features: Output HP: 3. Frequency: 60 Hz. Current: SF 15.0-13.6 A. Service factor: 1.15. Frame: Y56Y. Output KW: 2.2 kW. Voltage: 208-230 V. Speed: 3450 rpm. Phase: 1. Insulation class: F. Enclosure: drip proof. Ambient temperature: 50°C. Electrical type: permanent split capacitor, single or dual voltage. Rotation: counterclockwise pump end. Motor orientation: horizontal. Opp drive end bearing: ball. Shaft type: threaded. Mounting: square flange. Drive end bearing: ball. Dimensions: Shaft diameter: 0.62". Frame length: 10". Shaft extension: 0.91". Material(s): rolled steel/stainless steel
