B Plus B Smartworx 485USBTB-4W USB to Serial 1 Port RS-485, 4 Wire Converter

Universal Serial Bus (USB) has become the connectivity workhorse of today?s PCs, replacing the familiar serial ports. However, many commercial and industrial devices still use the RS-485 interface. To connect these devices to modern PCs, you need a simple and reliable conversion solution. The 485USB9F-2W and 485USB9F-4W offer this solution in a space saving, USB Port powered package.

Simply install the drivers supplied on CD ROM and plug the converter into an available USB port on your computer or USB hub. The device will show up as an additional COM port in the Windows Device Manager which is fully compatible with your Windows applications. Choose the 485USB9F-2W for RS-485 2-wire applications or the 485USB9F-4W for RS-485 4-wire applications. Locked serial number versions are also available. A one meter USB cable is included.

• Connect RS-485 Devices to your USB Port
• Perfect for Field Service Applications
• Small ? Fits easily into any laptop bag
• USB Port Powered
• USB 2.0 (12 Mbps) Compatible
• RS-485 Data rates up to 921.6 Kbps
• Supports Windows 98, ME, 2000, XP, Vista,7 (32/64 bit), 8 (32/64 bit)

• Serial Technology Data Rate: Up to 921.6 Kbps
• Serial Technology Connector: DB9 Female
• USB Technology Connector: USB Type B Female
• USB Technology Data Rate: 12 Mbps
• Power Source: USB Port
• Input Voltage: 5VDC
