Mean Well RS-100-24 Power Supply 100W 24V

Name: Mean Well RS-100-24 Power Supply 100W 24V
Brand: unknown
SKU: 5773522159
Price: 27.4 USD
Availability: InStock

(No ratings yet)

Key item features

Specs

Watts
100 Watts
Brand
unknown
Volts
24 V
Weight
15.4 lbs

Current price is $27.40

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Columbus, 43215

Arrives by Sat, Apr 11

Sold and shipped by Power Supply Mall

4.125 stars out of 5, based on 8 seller reviews(4.1)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Features

All using 105°C long life electrolytic capacitors

Protections: Short circuit / Overload / Over voltage

Meet EMS EN50082-2/EN61000-6-2

Heavy industry level (35~150W)

Withstand 300VAC surge input for 5 sec.

High operating temperature up to 70°C

Withstand 5G vibration test

Miniature size, high power density

High efficiency, long life and high reliability

LED indicator for power on

100% full load burn-in test

Suitable for critical applications

3 years warranty

General Specification

AC input voltage range	88~264VAC, 125~373VDC
AC inrush current (max.)	40A at 230VAC
DC adjustment range	±10% by potentiometer for single output; CH1 -5%~+10% by potentiometer for multiple output
Overload protection	110%~150% hiccup mode, auto-recovery
Over voltage protection	115%~135% rated output voltage, hiccup mode, auto-recovery
Withstand voltage	I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minute
Working temperature	-25~+70°C (refer to the derating curve for different models)
Vibration	10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards	UL60950-1, TUV EN60950-1 approved
EMC standards	EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2) (35~150W)
Connection	Terminal block for input and output
Dimension (LxWxH)	159x 97x 38
Case No.	901C
Packing	24pcs /15.4kg
