G8JN-1C7T-R-DC12 5Pins 12VDC 20A Automotive Power Relay

Nominal Coil Voltage: 12VDC

Contact From:SPDT

Contact material: Silver alloy

Resistive load: 20A

Operate time*2: Max.10ms at 13.5V (Normally 5.4 ms)

Release time*2 : Max.10ms at 13.5V (Normally 1.6 ms)

Insulation resistance:1000MΩ min.(at 500 VDC)

Operating ambient temperature: -40~ +125°C (no freezing)

Weight: Approx.34g

Package Content: 1 xG8JN-1C7T-R-DC12

Attention:

Do not switch the contacts without any load as the contact resistance may become increased rapidly.

Do not use relays that exceed coil ratings, contact ratings, and life expectancy, as doing so may result in Risk of overheating.
