CONSUMER INPUT JACKS-MONO

The D/S-CIJ3 is the ideal choice in installations requiring the passive mixing of two unbalanced line level audio sources to feed a mono balanced (or unbalanced) audio line. The D/S-CIJ3 is a complete unbalanced line-level audio input module. The front panel features two gold plated phono jacks and a single stereo mini-jack, intended for mono or stereo consumer level sources. An input signal may be connected to either the phono jacks or to the mini-jack. The left and right signal inputs are combined and balanced through audio transformers configured to reject induced hum. A mono line-level output is provided on the rear-panel detachable terminal block for connection to a 10 k? or higher input impedance line-level module or equipment input. Main Features � Stereo Inputs to Mono Output � Stereo Inputs on RCA Jacks and Stereo Mini-Jack � Unbalanced to Balanced Conversion Without Gain � Transformer Isolation for Unbalanced Line Inputs � Hum Cancellation on Unbalanced Line Inputs � Line-Level Output to Feed 10 k? Equipment Inputs � Output Connections on Detachable Terminal Block � Mix Stereo Inputs to Mono Balanced � Available in RDL White/Gray (D-CIJ3) � Available in Stainless Steel (DS-CIJ3)
