Beckett 7575P1515U 120v Genisys Primary Control 15 Second Pre And Post Purge

Beckett 7575P1515U 120v Genisys Primary Control Pre Purge 15 Sec. Post Purge 15 Sec. Epoxy potted for moisture resistance Lockout Time 15 Seconds Valve On Delay Time 15 Seconds Motor Off Delay Time 15 Seconds Electrical Ratings Inputs Voltage: 102 to 132 Vac Current: 150 mA plus burner motor, igniter, and valve loads Frequency: 60 Hz Electrical Ratings Outputs Motor: 120 Vac, 10 full load amps (FLA*), 60 locked rotor amps (LRA) Note – Reduce motor FLA rating by igniter current Igniter: 120 Vac, 3 A @ 0.7 PF min Solenoid Valve: 120 Vac, 1 A @ 0.7 PF min Features & Benefits ● Epoxy potted for moisture resistance ● Compatible with most operating controls ● Customizable pre-time and post-time ● Three status lights for system monitoring and diagnostics ● Welded relay protection with redundant motor relays ● Limited reset and limited recycle ● Sleek, modern design ● Technician Pump Prime mode ● 18 month Warranty ● Communication ports for the contractor tool (Sold Separate)
