Kramer 50-80317090 TP-590TXR HDMI Audio USB Bidirectional RS-232 & IR Over HDBaseT 2.0 Twisted Pair Transmitter

Name: Kramer 50-80317090 TP-590TXR HDMI Audio USB Bidirectional RS-232 & IR Over HDBaseT 2.0 Twisted Pair Transmitter
Brand: Kramer Electronics
SKU: 486761807
Price: 408.04 USD
Availability: InStock

(No ratings yet)

Key item features

Kramer MegaTOOLS TP-590TXR Video Extender Transmitter

Connectivity Technology: Wired
Form Factor: Rack-mountable
Connectivity Technology: Wired
Form Factor: Rack-mountable
Maximum Operating Distance: 330 ft
Transmitter Height: 1"
USB: Yes
Transmitter Width: 7.38"
Network (RJ-45): Yes
Media Type Supported: Twisted Pair

Specs

Rms power rating
50 W
Brand
Kramer Electronics
Height
1"
Color
MultiColor
In/Out type
HDMI
Input/output direction
Bi-Directional

Current price is Now $408.04

You save $167.96

was $576.00

Price when purchased online

Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $36.00

4-Year Plan - $49.00

How do you want your item?

Columbus, 43215

Arrives by Mon, May 11

Shipping fee $9.98

Sold and shipped by UnbeatableSale Local

4.114899579635685 stars out of 5, based on 6423 seller reviews(4.1)

Report an issue with this seller

Free 30-day returns

More seller options (1)

Starting from $418.02

About this item

Product details

TP-590TXR HDMI Audio USB Bidirectional RS-232 & IR Over HDBaseT 2.0 Twisted Pair Transmitter

The TP-590TXR is a high-performance, extended range, HDBaseT 2.0 transmitter for HDMI, USB2.0, audio, bidirectional RS-232 and IR signals. The TP-590TXR converts the HDMI, USB2.0, audio, RS-232 and IR input signals into an HDBaseT twisted pair signal that it sends to the TP-590RXR for decoding.

Features

Maximum Data Rate - 10.2Gbps (3.4Gbps per graphic channel).
HDTV Compatible.
HDCP Compliant.
HDBaseT V2 Support.
USB Support - USB1.1 & USB2.0 (up to 127Mbps).
Supports Isochronous USB Cameras.
HDMI Support - Deep color, x.v. Color, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, CEC, 2K, 4K, 3D.
EDID Pass Through - Passes EDID signals from the source to the display.

Specifications

Inputs: 1 HDMI on an HDMI connector, 1 stereo analog audio on a 3.5mm mini jack
Outputs: 1 HDBT on a RJ-45 connector, 1 USB2.0 on a USB connector
RS-232 Baud Rate: 115200
Compliance With HDMI Standard: Supports HDMI and HDCP
Operating Temperature: 0° to +40°C (32° to 104°F)
Storage Temparature: -40° to +70°C (-40° to 158°F)
Humidity: 10% To 90%, Rhl Non-Condensing
Power Consumption: 12V DC, 720mA

- SKU: TCNCD294187

Kramer MegaTOOLS TP-590TXR Video Extender Transmitter

Connectivity Technology: Wired
Form Factor: Rack-mountable
Connectivity Technology: Wired
Form Factor: Rack-mountable
Maximum Operating Distance: 330 ft
Transmitter Height: 1"
USB: Yes
Transmitter Width: 7.38"
Network (RJ-45): Yes
Media Type Supported: Twisted Pair

info:

We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Rms power rating

50 W

Inputs/Outputs

1 HDMI on an HDMI connector, 1 stereo analog audio on a 3.5mm mini jack, 1 HDBT on a RJ-45 connector, 1 USB2.0 on a USB connector

Brand

Kramer Electronics

Accessories

MegaTOOLS TP-590TXR Video Extender Transmitter, Power Supply (48V, 1.36A)
