Honeywell V8044E1011 24v Zone Valve (3/4" Sweat, Divert, W/End Sw)

Honeywell V8044E1011 3 Way Diverting 3/4" Sweat 24V Zone Valve With End Switch Commonly Used On Fan Coil Applications Specifications: Voltage: 24 Vac Size: 3/4" I.D. (7/8" O.D.) Connection Type: Sweat Body Pattern: 3-Way Diverting Position: Normally Closed Flow Capacity (Cv): 7 Max Close-Off PSI: 10 psi End Switch: Yes Features: Opening the 3rd port does not cause any of the other ports to close On-off and diverting line voltage valves consist of an actuator motor and valve assembly for controlling the flow of hot or chilled water. Manual opener (on all models, except straight-through, normally open valves) for valve operation on power failure; valve returns to automatic position when power is restored. All models may be installed without disassembling the valve. Compact construction for easy installation. Complete powerhead may be removed or replaced without breaking plumbing line connections or draining the system. Actuator motor may be replaced without removing the valve body or draining the system. Replaces- Erie: VT3317G13A02A, 07VT3317G13A02A, VT3317G13A02A
