Faria Boat Multifunction Gauge GTC067A | 5 Inch Premier Pontoons

Boat part number 7910414 is a new Premier Pontoons multifunction gauge from Faria, part number GTC067A .

This gauge uses the following functions:

• 7000 RPM Tachometer
• Mercury/Yamaha Trim

This clear LED illuminated gauge features a domed lens, gray and black colored face, silver colored bezel, black and white lettering, numerals and accents, with red needles.

Measures approximately 4 3/4" OD (including bezel) x 4 1/4" D overall. Manufacturer calls this a 5" gauge and requires an approximate 4 3/8" Dia. cutout. Hosts (2) threaded bolts, (1) 6-pin male Deutsch, and (1) 6-pin female Deutsch connections. Set up for 4/6/8 cylinder and 4/6/8/10/12 pole engines. Set up for gasoline Mercury and Yamaha engines.

Switch settings read as the following:

• 1 - 4 POLE/CYL
• 2 - 6 POLE/CYL
• 3 - 8 POLE/CYL
• 4 - 10 POLE
• 5 - 12 POLE

Mounting bracket included.

Specifications:

• Boat Manufacturer: Premier Pontoons
• Part Manufacturer: Faria
• Part Number: GTC067A
• Colors: Gray and Black (Face) | Silver (Bezel)
• Manufacturer Size: 5"
• Overall Dimensions: 4 3/4" OD x 4 1/4" D
• Cutout: 4 3/8" Dia.
• Connections: (2) Threaded Bolts | (1) 6-Pin Male Deutsch | (1) 6-Pin Female Deutsch
• Fuel: Gas
• Set up for 4/6/8 Cylinder and 4/6/8/10/12 Pole Engines
• Set up for Mercury and Yamaha Engines.

Pigtail connector / harness not included.

Wiring diagram NOT included. You will need to check with a dealer for the proper pin/wiring sequencing.

Sold as seen in pictures. Customers please note every computer shows colors differently. All measurements are approximate.

Hardware and instruction / installation manual not included.
