Adj, Alternating Relays, 4, 12v, PIC510 Kit

This will turn ON one Relay at a time, while the others are OFF, then turn ON the next Relay, while all the others are OFF and so forth. It will then go to the first one and repeat the process as long as power is applied.The ON-Time is adjustable from 1 second to 4 minutes. Contact us for different times. There is a Jumper on board that will allow you to double the ON Times. The ON-Times are controlled by a Microchip PIC microprocessor.For those with Microchip PIC programming experience, the PIC12F510 may be removed and re-programmed as desired.The Relay contacts are rated for 7 Amps @ 125VAC. The contacts are Form C with a COM, NO & NC outputs available. The Relay is either a 833 or JS1 series. There is a LED on board that comes on whenever the Relay comes on. The input power is 12vdc. The Relay coil is 12v. There is an on-board Voltage Regulator (5v) for the PIC microprocessor.
