GM F/X-Body 67-69 Camaro 4-Speed/TKO Manual Transmission Swap Kit

4-Speed or Tremec TKO Transmission swap kit for 1967-69 F-Body Camaro/Firebird and X-Body. Kit includes hydraulic clutch conversion, hydraulic throwout bearing, and transmission crossmember. McLeod 1434002 Hydraulic Clutch Conversion Kit Fits 1967-1969 Camaro & Firebird (when used with Camaro pedal box) and 1967-1974 Nova. 3/4" master cylinder bore size. Master cylinder included. Self-adjusting bearing feature. GM Stock Clutch Hydraulic Throwout Bearing Stock-style 3-speed and 4-speed. Retainer preventss over extension and seal damage. Small to fit "thicker" stock style clutches. G Force RCF1-700 Transmission Crossmember Mounting hardware included. Black powder coat finish. Clearance for large diameter dual exhaust system. 30-3/8" distance between crossmember frame holes. This crossmember is installed with the GForce label facing the REAR of the vehicle. A second determining feature is the crossmember center tube section has a 1/2" in. drain hole located on the BOTTOM and on the PASSENGER side next to the exhaust hump weldment. To utilize the provided 7/16 hardware it is necessary to enlarge the holes in the frame rails. If the installer chooses to utilize the stock size 3/8 hardware, it is strongly recommended that the installer obtains Grade 8 fasteners and washers to compensate. GM Stock Clutch Hydraulic Throwout Bearing The fittings are -4 AN male for the "feed" and the "bleed" lines. Both fittings are tapped internally to accept the bleeder. Bleeder threads are 1/4"-28. To build your own external bleeder for this bearing, purchase (1) each of the following parts: 835-2200063 (1/8" bleeder) 617-4025 (-4 AN to 1/8" female) 91031842-4 (12" -4 AN line) GM Stock Clutch Hydraulic Throwout Bearing The fittings are -4 AN male for the "feed" and the "bleed" lines. Both fittings are tapped internally to accept the bleeder. Bleeder threads are 1/4"-28. To build your own external bleeder for this bearing, purchase (1) each of the following parts: 835-2200063 (1/8" bleeder) 617-4025 (-4 AN to 1/8" female) 91031842-4 (12" -4 AN line)
