LSTA12 Strap Tie

LSTA12 Strap Tie HRS/ST/PS/HST/HTP/LSTA/LSTI/MST/MSTA/MSTC/MSTI Strap Ties Straps are designed to transfer tension loads in a wide variety of applications. HRS - A 12 gauge strap with a nailing pattern designed for installation on the edge of 2x members. The HRS416Z installs with Simpson Strong-Tie Strong Drive SDS screws. LSTA and MSTA - Designed for use on the edge of 2x members, with a nailing pattern that reduces the potential for splitting. LSTI - Light straps that are suitable where pneumatic-nailing is necessary through diaphragm decking and wood chord open web trusses. MST - Splitting may be a problem with installations on lumber smaller than 3 1/2"; either fill every nail hole with 10dx1 1/2" nails or fill every-other hole with 16d common nails. Reduce the allowable load based upon the size and quantity of fasteners used. MSTC - High Capacity strap which utilizes a staggered nail pattern to help minimize wood splitting. Nail slots have been countersunk to provide a lower nail head profile. Finish: PSHDG; HST3 and HST6Simpson Strong-Tie gray paint; all othersgalvanized. Some products are available in stainless steel or ZMAX coating; see Corrosion Information. Installation: Use all specified fasteners. See General Notes. Some products may be installed with the Strong-Drive SD Structural Connector screw Options: Special sizes can be made to order. Contact Simpson Strong-Tie. Codes: MSTC and RPS meet code requirements for reinforcing cut members 16 gauge at top plate and RPS at sill plate. International Residential Code- 2000/2006 R602.6.1 International Building Code- 2000/2006 2308.9.8
