200PCS 3:1 Heat Shrink Tubing Dual-wall Adhesive Lined Tube 7 Sizes 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8" for Electronic Electrical Cables Battery Terminal Connectors Wire Lugs Daily Repair

Hero image 0 of 200PCS 3:1 Heat Shrink Tubing Dual-wall Adhesive Lined Tube 7 Sizes 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8" for Electronic Electrical Cables Battery Terminal Connectors Wire Lugs Daily Repair, 0 of 6

RockDIG

200PCS 3:1 Heat Shrink Tubing Dual-wall Adhesive Lined Tube 7 Sizes 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8" for Electronic Electrical Cables Battery Terminal Connectors Wire Lugs Daily Repair

Name: 200PCS 3:1 Heat Shrink Tubing Dual-wall Adhesive Lined Tube 7 Sizes 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8" for Electronic Electrical Cables Battery Terminal Connectors Wire Lugs Daily Repair
Brand: RockDIG
SKU: 2114579303
Price: 21.99 USD
Availability: InStock
Rating: 5 (2 reviews)

|2 ratings

Key item features

SPECIFICATION:

Material: Polyolefin

Shrinkage ratio: 3:1

Starting shrinkage temperature: ≥ 70 ℃

Full shrinkage temperature: ≥105 ℃

Operating temperature: -45 ℃ to 125 ℃

Tensile strength: 10.4Mpa

Dielectric strength: 15 kV/mm

Voltage: 600V

Flammability: Flame Retardant

FEATURES:

3:1 Shrinkage ratio heat shrink tubing, will shrink up to 1/3 of the original diameter, suggest to use a heat gun to shrink it.
Double-wall Adhesive Lined, with coated hot melt adhesive to prompt the sealing waterproof performance.
Including 7 Popular Sizes: 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8", Mix 2 colors Black and Red, suitable for copper AWG wire lugs size ranges from AWG 2/0 1/0 2 4 6 8 to Gauge 10-12 12-14 22-16.
Suitable for electrical insulation, wire bundling, mechanical protection, cable joints and daily repairs etc.

PACKAGE INCLUDES:

Φ1/8" --- length 1.5" ----- 52pcs (black - 26pcs, red - 26pcs);
Φ3/16" --- length 1.5" ----- 52pcs (black - 26pcs, red - 26pcs);
Φ1/4" --- length 1.5" ----- 56pcs (black - 28pcs, red - 28pcs);
Φ3/8" --- length 3" ----- 12pcs (black - 6pcs, red - 6pcs);
Φ1/2" --- length 3" ----- 12pcs (black - 6pcs, red - 6pcs);
Φ3/4" --- length 3" ----- 10pcs (black - 5pcs, red - 5pcs);
Φ1" --- length 3" ----- 6pcs (black - 3pcs, red - 3pcs).

Total: 200pcs pre-cut heat shrink tubings.

HOW TO USE?

Choose the right size tubes, as it is 3:1 heat shrink ratio, it will shrink up to 1/3 of the original diameter. Pease measure and make sure the diameter of wire is equal or a bit larger than the size of tube after heat shrink.
Insert the wires to the heat shrink tubing, use a lighter heating if the tube is small, heat guns heating for large one until the wire is wrapped tightly.
Don't touch the tube until it cool completely.

Specs

Wire connector type
Heat Shrink Tubing
Features
Waterproof
Brand
RockDIG
Color
balck, red
Pieces
200
Model
WLTB200

Price when purchased online

Report an issue with this seller

More seller options (1)

Starting from $21.99

About this item

Product details

The heat shrink tubing is a shrinkable plastic tube which used to insulate wires. It provides abrasion resistance and environmental protection for electical works. We can use it for stranded and solid wire conductors, connections, joints and terminals in electrical wiring projects. And use it to repair the insulation on wires or to bundle them together, to protect wires or small parts from minor abrasion, and to create cable entry seals. Our 3:1 heat shrink tubing is made of polyolefin, which shrinks radially (but not longitudinally) when heated, to 1/3 of its diameter. All of our heat shrink tubings meet the requirment of CE, RoHS and UL, you can use it with full confidence.

SPECIFICATION:

Material: Polyolefin

Shrinkage ratio: 3:1

Starting shrinkage temperature: ≥ 70 ℃

Full shrinkage temperature: ≥105 ℃

Operating temperature: -45 ℃ to 125 ℃

Tensile strength: 10.4Mpa

Dielectric strength: 15 kV/mm

Voltage: 600V

Flammability: Flame Retardant

FEATURES:

3:1 Shrinkage ratio heat shrink tubing, will shrink up to 1/3 of the original diameter, suggest to use a heat gun to shrink it.
Double-wall Adhesive Lined, with coated hot melt adhesive to prompt the sealing waterproof performance.
Including 7 Popular Sizes: 1" 3/4" 1/2" 3/8" 1/4" 3/16" 1/8", Mix 2 colors Black and Red, suitable for copper AWG wire lugs size ranges from AWG 2/0 1/0 2 4 6 8 to Gauge 10-12 12-14 22-16.
Suitable for electrical insulation, wire bundling, mechanical protection, cable joints and daily repairs etc.

PACKAGE INCLUDES:

Φ1/8" --- length 1.5" ----- 52pcs (black - 26pcs, red - 26pcs);
Φ3/16" --- length 1.5" ----- 52pcs (black - 26pcs, red - 26pcs);
Φ1/4" --- length 1.5" ----- 56pcs (black - 28pcs, red - 28pcs);
Φ3/8" --- length 3" ----- 12pcs (black - 6pcs, red - 6pcs);
Φ1/2" --- length 3" ----- 12pcs (black - 6pcs, red - 6pcs);
Φ3/4" --- length 3" ----- 10pcs (black - 5pcs, red - 5pcs);
Φ1" --- length 3" ----- 6pcs (black - 3pcs, red - 3pcs).

Total: 200pcs pre-cut heat shrink tubings.

HOW TO USE?

Choose the right size tubes, as it is 3:1 heat shrink ratio, it will shrink up to 1/3 of the original diameter. Pease measure and make sure the diameter of wire is equal or a bit larger than the size of tube after heat shrink.
Insert the wires to the heat shrink tubing, use a lighter heating if the tube is small, heat guns heating for large one until the wire is wrapped tightly.
Don't touch the tube until it cool completely.

info:

We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Wire connector type

Heat Shrink Tubing

Features

Waterproof

Brand

RockDIG

Color

balck, red

Warranty

Warranty information

Please be aware that the warranty terms on items offered for sale by third party Marketplace sellers may differ from those displayed in this section (if any). To confirm warranty terms on an item offered for sale by a third party Marketplace seller, please use the 'Contact seller' feature on the third party Marketplace seller's information page and request the item's warranty terms prior to purchase.
