(Price/Each)Honeywell VU54S2008 1/2" Sweat 3 Way Fan Coil Valve Body 4 Cv, 20 PSI Differential. Short Body, Replaces VU54S1000

Price is for each.

Manufacturer Part Number: VU54S2008

HONVU54S2008 1/2 Sweat 3 Way Fan Coil Valve Body 4 Cv 20 PSI Differential. Short Body Replaces VU54S1000

Part Description:

• Fan Coil Zone Valve
• Type 3-Way, A-AB-B
• Nominal Size 1/2 Inch
• End Connection Soldered x Soldered
• Actuation Type Diverting
• Body Material Brass
• Temperature Rating 200 Deg F (Fluid)
• Pressure Rating 20 PSI (Close-Off), 300 PSI (Static)
• Media Handled Hot/Chilled Water, Glycol
• Inclusions/Features Quick Opening Flow
• Application Commercial HCAC Equipment, Fan Coil Unit, Terminal Reheat Coil and Convector
• Applicable Standard CSA (Canada and US)
• Overall Dimension 3-1/2 Inch Width
• Flow Capacity 4 Cv
• Material Brass (Seat/Stem), EPDM Rubber (Packing), Buna-N Rubber Ball (Plug/Ball/Disc)
• Ambient Temperature 34 to 125 Deg F
• Used With VU444 or VU844 Actuator

Features / Benefits

• Compact Construction for Easy Installation
• Fits Under the Cover of Most Baseboard Convectors with Actuator Fitted to Valve Body
• Patented Ball Seal Provides Long Service Life, Soft Close Off
• Triple O-Ring Seal Provides Three Lines of Defense Against Corrosion and Water Leakage Around Drive Shaft
