60V 50A Bench Source Laboratory Dc Stabilized Power Supply Adjustable, Variable Digital Regulated Power Supply 100,20A ,Voltage Consistency

High-power digital display program-controlled switching DC regulated power supply newly developed and upgraded . This product is a DC programmable power supply with exquisite appearance, small size, high performance, powerful function and simple operation. It is suitable for testing in aerospace and defense, consumer electronics, computers and peripherals, communications, semiconductors, solar energy and automotive electronics. The product can display voltage and current at the same time. The output voltage and output current are adjusted by the encoder knob, which can be continuously adjusted between 0 and the nominal value. It has high power, large current, fast response, and fast load transient response, Low noise, easy to use and other significant advantages! The stability and ripple coefficient of the power supply are very good. It has various protection circuits such as short-circuit protection, over-voltage protection, over-current protection, over-temperature protection, etc., which can work at full load for a long time and is deeply loved by users.

Application field: Electrolytic plating , Product aging test , Production, line test, Charging batteries,Electronic device testing,Laboratory research and development test,School teaching experiment,Telecom Power

Operation requirements

Input voltage:AC ±10%;50Hz

<80%RH

<70%RH

Set value resolution

Voltage0.01V Current0.01A

Resolution of readback value

Voltage0.01V Current0.01A

Header display

0.56 inch white four-digit digital tube display

Display accuracy: 0.5%±3 words

Display resolution: voltage 0.01V, current 0.01A

Regulated state CV

Voltage stability:0.5%±20mV

Load stability:0.5%±20mV

Ripple voltage:0.5%Vp-p

Steady flow state CC

Current stability:0.5%±20mA

Load stability:0.5%±20mA

Ripple current:0.5%Vp-p

Temperature Coefficient:100ppm/

Rise Time

No load15ms Fully loaded30ms

Dynamic response time

2ms

Accessibility

OUTPUT output switch, OCP short circuit protection switch

Protective function

OVP,OCP,OPP,OTP

Random accessories

1 Small size, light weight, suitable for work surface use and rack installation;

2 Exquisite appearance, flexible operation and convenient use;

3 High precision, internal use original chip, stable and reliable performance;

4 Using high-gain amplifier circuit design, with good fast load transient response to prevent unwanted voltage offset;

5 Using PWM modulation, high efficiency, more power saving;

6 Intelligent temperature control fan with low noise

7 Built-in OVP over-voltage protection, OCP over-current protection, OPP overload protection, OTP over-temperature protection, complete and reliable protection functions;

8 Voltage and current preset, OUT output function

9 The product has a short-circuit protection alarm function
