2CH HDS2202S 200MHz 1GSa/s Handheld Oscilloscope Multimeter 25MHz Waveform Signal Generator 3.5inch USB Test Tool ,Professional Designed

Specifications

Battery Demountable Yes

Max Waveform Capture Rate 30,000wfm/s

Record Length 8K

Model Number HDS2202S

Real Time Sampling Rate 1GSa/S

Display resolution 320*240 Pixels

Display Size 3.0 - 4.9 Inches

Band Width 100-349MHz

Digital Channels 2

DIY Supplies ELECTRICAL

Feature 1

200MHz Bandwidth

Feature 2

1GSa/s Sample Rate

Feature 3

25MHz Waveform Generator

Feature 4

3 in 1 Handheld Oscilloscop

Oscilloscope is the most commonly used tool for designing and testing electronic devices and devices. Digital storage oscilloscopes (DSO) and mixed signal oscilloscopes (MSO) are powerful instruments used to display and measure electronic signals that change over time, and can help determine which device is operating normally and which device is malfunctioning. An oscilloscope can also help you determine whether newly designed devices can operate as you want

What is an oscilloscope and why do you need it?

Signal integrity

The main purpose of an oscilloscope is to accurately display electronic signals. Therefore, signal integrity is very important. Signal integrity refers to the ability of an oscilloscope to reconstruct waveforms and accurately display the original signal. Due to the meaningless testing when the waveform of the oscilloscope is different from the real signal, an oscilloscope with low signal integrity is of no value. However, no matter how high the performance of the oscilloscope is, it cannot fully reproduce the real signal. This is because when you connect the oscilloscope to the circuit, it becomes a part of the circuit. In other words, there will be some load effects. Although instrument manufacturers try their best to minimize load effects, they still exist to some extent.
