52mm Fuel Level Gauge Fuel Level Sensor 0~190 Ohm 240-33ohm With Red Backlight For Car Boat Motorcycle Indicator E-F Range 9-32V ,Easy Setup

52mm Fuel Level Gauge Fuel Level Sensor 0~190 Ohm 240-33ohm With Red Backlight For Car Boat Motorcycle Indicator E-F Range 9-32V

Feature:

-Resolution range: 21 mm

- Digital Fuel Level Gauge & Sensor Floating Combination

Digital LED light display knowing the oil level status real-time

- The front cover is made of 316 stainless steel,It can be used for a long time even in an acid-base or humid environment.

- The harness connector has a snap to ensure a secure connection between the meter and the harness, it is still reliable in applications where vibration is strong.

- Fine waterproof structure design, waterproof and dustproof rating: IP67

Feature:

- Signal: 0-190ohm/240-33ohm

- Range: E-1/2-F

- Working volt:9-32VDC

- Operating current: 60mA

- Operating temperature: -30~+75

- Storage temperature: -40~+85

- Gauge Diameter: 52mm / 2inch

-Backlight Color: RED LED

- Alarm Mode: Red Indicator Light Flashes

- Alarm Set Point: <13%

Attention:

- Empty oil level : 0 ohm /240ohm

- Full oil level : 190 ohm /33ohm

- When the oil / water level is empty , there will be a space of 3-21mm between the sensor float and the bottom of the sensor. This is a safe distance, and the sensor can work normally,Thank you~

- When the oil / water level is full, there will be a space of 3-15mm between the sensor float and the top of the sensor. This is a safe distance, and the sensor can work normally, Thank you~
