for AV2HD: AV to HDMI Converter with 1080p Support, Plug & Play

Mini HD to AV Converter:

Feature:

Change HD video / audio signal to AV (CVBS) composite video signal and the FL / FR stereo audio signals, while support DVI system sideline signals, convert the HD digital signal into AUDIO Analog Stereo Sound via DAC processing.

Employs the latest video processing technology, enhance the picture's Brightness / Contrast Ratio / Color, its Output CVBS Transparency is Ultimate Clear.

Adopts 3D Compensation Technology, help to eliminate the video's Jitter & Drag effectively / Adopts the technology of Low-power-consumption Digital Chips, Low-heat generating, stable, 24h persistent working.

Change the high quality of the HD video signal into normal CVBS signal, so that enables you to play on TV, VHS VCR, DVD recorders, etc.

Automatically identify HDCP, directly crack the KEY (HDCP) from Front HD Port.

Also supports NTSC and PAL two TV format.

Specification:

Input Port: 1 X Standard HD

Output Port: 1 X 3RCA ( Yellow / White / Red )

HD Input Resolution: 1080p

CVBS Output: PAL / NTSC_M (NTSC_J)

Size: 66 X 55 X 20 mm ( L * W * H )

Weight: 60g

Package Content:

1 x Mini HD to AV Converter

1 x USB Cable

1 x User Manual

Product B : AV2HD



AV to HDMI Converter:

Description:

It converts RCA (AV, composite, CVBS) signals into HD signals so you can watch your video on a modern TV with HD ports.

The analog to digital conversion in this module employs 10 bits maximal 162MSPS sampling, black/white level expansion,

color transition improvement, dynamic range expansion, blue stretch , auto-detect and auto-convert the composite signal to 1080p(60HZ) output.

Making video come alive, delivering the sharpest, most realistic HD visuals available.

Converts analog composite input to HD 1080p (60HZ) output,displayed on 1080p (60HZ) HDTV/Moniter.

Support HD 1080p or 720p output. Provide advanced signal processing with great precision,colors, resolutions, and details.Plug and play.

Support PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N standard TV formats input.

Specifications:

1. Input ports: 1xRCA (Yellow, White, Red), USB power

2. Output ports: 1xHD(standard)

3. NTSC/PAL compatible

4. Composite input: PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N

5. HD output: 1080p/60Hz, 720p/60Hz

6. Dimensions (mm): 66(D)x55(W)x20(H)

7. Weight (g): 60g

8. Power: USB Port

Features:

No need to install drivers, portable, flexible, plug and play.

Output the audio synchronization with video.

Can be displayed on Moniter/ TV with 1920x1080@60Hz High bandwidth capability

Package:

1 x AV to HDMI Converter

1 x USB Power Cable

1 x User Manual
