800V Digital Capacitor Fast Discharger High Voltage Discharge Tool Blue

800V Digital Capacitor Fast Discharger High Voltage Discharge Tool Blue

Features:

This is a small capacitor discharge tool with a DC voltmeter, which can display AC and DC voltage values. It has a fast discharge speed, is safe and spark-free, and is an essential tool for electronic maintenance personnel.

Small size, light weight, and easy to carry.

Fast discharge speed, no sparks

Discharge does not distinguish between positive and negative poles.

The 4-digit 8888 digital tube displays the remaining voltage and can be used as a voltmeter.

Applicable to DC voltage discharge below 800V.

Specifications:

Part name: capacitor discharge pen

Material: ABS

Discharge voltage range <800VDC

Color: blue, red

Size: as shown in the figure

Maximum discharge energy (joule): 150J

Input port: 4mm banana head.

Probe cover material: antifreeze PVC.

Use: Discharge capacitors such as switching power supplies, digital cameras, TV power boards, high-voltage large electrolytic capacitors, etc.

Function: Discharge capacitors to protect products and operators from electric shock.

Guide to use

LInsert the red and black test leads into the 4mm banana head.

L Touch the red and black test pen tips to the two pins of the capacitor, regardless of the positive and negative poles.

L The voltmeter will display the residual voltage
