The AC distribution panel is rated for 240 V AC at 50 amps. Provisions for up to 12 branch circuit breakers plus a center feed dual 50 amp main breaker (not included). 12 Built-in push and lock strain relief wiring connectors. Attractive lightweight panel design made from black impact-resistant high temperature polymers. Top two fuse holders recommended for low current devices such as smoke and carbon monoxide detectors. Optional 12 branch fuse holders with 2-30 amp circuits or 18 branch fuse holders with 4-30 amp circuits. Maximum rating 20 amps on remaining circuits with optional wire tail connections. Optional l. E. D. Indicators identify which fuse is blown. Converter/charger section is accessible from the front. Converter/charger ratings of 60, 75 & 90 amps which is the largest rating in the industry. Easy access reverse battery protection fuses. Optional dc disconnect tie in.
Features - Reverse battery protection
- Electronic current limiting
- High and low AC input protection
- Intelligent, variable speed, cooling fan
- Automatic thermal protection
- Press open door for easy access to circuit breakers
- Front access to large wiring compartment
- Optional DC ground bus can be user installed in the DC wiring compartment
Specifications - Color: Black
- Current in Amps: 75A
- Panel Size: 10.125 x 13.25"
- Weight: 6 lbs
- SKU: MYRD83522
