SMSL C200 USB DAC Home Audio Amp HiFi Decoder Bluetooth DAC Headphone Amplifiers
Key item features
- High-End DAC Chip: Features ESS ES9038Q2M D/A chip and 4 high-end dual OP amp OPA1612 for superior audio quality.
- Versatile Connectivity: Supports USB, Optical, Coaxial, and Bluetooth inputs, with RCA, TRS, 4.4mm, and 6.35mm headphone outputs.
- Bluetooth 5.1: Equipped with Bluetooth 5.1 chip supporting LDAC, APTX/HD, SBC, and AAC for high-resolution wireless audio.
- USB Compatibility: USB1.1 mode works with Switch, XBOX, PS4, PS5 without drivers; USB2.0 mode requires drivers for Windows systems.
- Advanced Audio Processing: Supports DoP64, native DSD512, and PCM up to 32bit/768kHz; Coaxial and optical support DOP64.
- Premium Build: Gold-plated input/output terminals, discrete component linear power supply, and multiple low-noise power supplies.
- Compact Design: Measures 139 x 32 x 147.5mm and weighs 510g, making it a compact yet powerful audio solution.
- Included Accessories: Comes with a remote control, Bluetooth antenna, USB cable, AC power cable, user manual, and warranty card.
Specs
- In/Out typeRCA
- BrandSmsl
- Signal-to-noise ratio126 dB
- Gain level11 dB
- Model nameSMSL C200
- ColorBlack
How do you want your item?
About this item
Product details
SMSL C200 Bluetooth USB Audio DAC Headphone Amp
How does the XBOX work with the C200? Xbox Series S and Xbox Series X need to use audio separator and C200 connection, can not be connected directly. The XBOX ONE can be connected to the C200 via OPT, without the need for an audio separator.
C200 is ESS D/A chip ES9038Q2M.
Bluetooth chip supports LDAC 24bit/96kHz, APTX/HD, SBC, AAC.
Audio clock processing circuit, greatly reducing the clock.
Product Specification
Input: USB/Optical/Coaxial/Bluetooth
Output: 6.35mm headphone / 4.4mm headphone / TRS/ RCA
Output Level: TRS: 4.0Vrms; RCA: 2.0Vrms
Headphone output power: 6Ω:2.6Wx2; 32Ω:1.3Wx2
Headphone Gain: low gain 0dB; high gain: 11dB
THD+N: line out: 0.0001% (-120dB); HP out: 0.00013% (-117dB)
Dynamic range: TRS: 126dB ; RCA: 125dB ; HP out: 123dB
SNR: TRS:126dB; RCA: 124dB; HP out:123dB
Output impedance : Line out 100Ω; HP out Near 0Ω
USB transmission: USB1.1; USB2.0(Asynchronization)
USB compatibility: Windows 7/8/8.1/10/11(Needs Driver);
Applicable to various systems.
Bit depth: USB 1bit; 16~32bit Opt / Coaxial 1bit; 16~24bit
Sampling rate: USB PCM 44.1~768kHz ; DSD 2.8224~22.5792MHz; Opt/ Coaxial PCM 44.1~192kHz DSD: DSD64(DoP)
Bluetooth specification: 5.1
LDAC: 24bit/96kHz (990kbps/660kbps/330kbps) aptX-HD: 24bit/48 kHz_576kbps aptX: 16bit/44.1 kHz_352kbps SBC: 16bit/44.1 kHz_328kbps AAC: 16bit/44.1 kHz_320kbps
Power Consumption: 5W
Standby power: <0.5W
Size: 139 x 32 x 147.5mm (WxHxD)
Weight: 510g/1.12Ibs
Accessories:
1x SMSL C200;
1x Remote control;
1x Bluetooth antenna;
1x USB cable;
1x AC power cable;
1x User manual;
1x Warranty card
If there is no sound in the output? Please try to restore the C200 to the factory setting: Under not powered on, press and hold the knob, and then use the adapter to power on, until the screen lights up, and then release the knob.
- 【SMSL C200 DAC】C200 is ESS high-end D/A chip ES9038Q2M; 4 x high-end dual OP amp OPA1612 and a large number of audio grade components; Bluetooth5.1 chip support LDAC transmission, 24bit/96kHz, APTX/HD, SBC, AAC.
- 【Multiple input and output modes】SMSL C200 audio dac support RCA single ended line/TRS balanced output/4.4mm balanced/6.35mm Earphone Jack Output and USB/Optical/Coaxial/Bluetooth input. Two kinds of headphone output jack to meet different headphone needs.
- 【USB INPUT Support Game console connection】U1.1 mode: Could work with Switch XBOX,PS4,PS5. All USB devices can be connected without driver. USB1.1 only supports up to 24bit/96kHz. U2.0 mode: USB2.0 needs driver with WIN system.
- 【2nd generation XMOS solution】C200 supports DoP64 and native DSD512, and PCM supports up to 32bit/768kHz; Coaxial and optical supports DOP64.
- 【High Quality Design】C200 with high quality gold plated input and output connection terminals. Built-in discrete component linear power supply and multiple low-noise power supplies for analog circuits. With remote control.
Specifications
In/Out type
Brand
Signal-to-noise ratio
Gain level
