1/2" DN15 Two wires control Normally Open Electric Ball Valve,AC110-230V Brass two-way Motorized Ball Valve

Technical Parameter
★ Product Size: 1/2", DN15
★ Valve Shread Option: NPT
★ Circulation Medium: Air, Water, Oil
★ Working Voltage: AC110-230V
★ Wiring Methods: CR202 Normally Open
★ Working Current: ≤ 500 mA
★ Actuator Material: PPO
★ Valve Body Material: Brass
★ Sealing Material: FKM & PTFE
★ Torque: 3 N.m
★ Protection: IP67
★ Actuator Rotation: 90 °
★ Open/Close Time: ≤ 5 Sec
★ Manual Override: No
★ Position Indicator: Yes
★ Power Cord Length: 0.5 m
★ Maximum Working Pressure: 1.0 MPa ( 145 Psi )
★ Environment temperature: -15℃ ~ 50℃ ( 5℉-122℉ )
★ Liquid temperature: 2℃ ~ 90℃ ( 35.6℉-194℉ )

Applicable occasion
♥ 1. HVAC;
♥ 2. Solar water heaters, solar water supply equipment;
♥ 3. Fire fighting equipment, medical equipment, cleaning equipment;
♥ 4. Automatic control system, automatic irrigation and drainage equipment;
♥ 5. Water treatment systems, drinking water equipment, efficient water-saving appliances;
♥ 6. Industrial self-control small equipment, environmental protection and other fields, can be used in occasions where the solenoid valve does not work properly.
