AMPHENOL/HOLLAND SCREW-ON MOCA PoE FILTER FOR CABLE TV & OTA INDOOR APPLICATION ONLY - LPF-1002-70

KEY FEATURES;

AMPHENOL/HOLLAND AMP-LPF-1002-70 MOCA™ PRIMARY ENTRY “PoE” FILTER

THIS DEVICE IS INTENDED FOR INTERIOR INSTALLATIONS APPLICATION ONLY, THE DEVICE IS NOT WATERPROOF.

TYPICAL MOCA COAXIAL NETWORKS WILL REQUIRE ONLY ONE “PoE” FILTER INSTALLED AT THE COAXIAL CABLES’ ENTRY TO THE RESIDENTIAL DWELLING OR COMMERCIAL BUILDING.

THIS FILTER CAN NOT BE USED IN CONJUNCTION WITH ANY SATELLITE SERVICES TRANSMITTED ON THE SAME COAXIAL CABLE. NOTE; THIS FILTER DOES NOT PASS AC/DC VOLTAGES, IF THESE ARE APPLIED THE DEVICE WILL BE DESTROYED.

BANDSTOP PROVIDES A TYPICAL -70DB OF REJECTION IN THE MoCA 1125-3000MHZ BAND. TYPICALLY ANOTHER MODEM PoE FILTERS PROVIDE NO GREATER THAN  -40DB OF MOCA BAND REJECTION.

AMPHENOL/HOLLAND MoCA FILTER IS DESIGNED TO REMOVE ANY INFERENCE THAT WOULD DISABLE THE AGC CIRCUITS OF DOSCIS 3.1 OR LOWER CABLE MODEM OPERATIONS, THE FILTER IS DOCSIS 3.1 COMPLIANT AND READY TO PROVIDE ANY SERVICES THAT WILL COME FORTH IN THE FUTURE.

THE FILTER PROVIDES INTERNAL SURGE PROTECTION RATED TO SURPASSING IEEE TESTING OF 6KV B3 COMBO WAVE SURGE TESTS.

DEVICES ARE DESIGNED TO REMAIN STABLE IN ENVIRONMENTS OF -40°F (-40°C) TO +140°F (+65^O C) AND MAINTAIN ALL TECHNICAL SPECIFICATIONS.

METALLIC HOUSING OF THE PROTECTOR PROVIDES EXCELLENT EMI SHIELD, EFFECTIVE BEYOND 140DB.
