Genrics 302-2 Engine Oil Pan Kit For Chevy Nova Camaro LS1 LS2 LS3 LS6 5.7L 5.3L 6.5L

LS engine Low Profile cast aluminum engine oil pan

Gen III/IV  blocks

4.8 - 5.3 - 5.7 -  6.0 - 6.2

LS1 - LS2 - LS3

Sump Style  ---    Wet

Sump Location  ---     Rear

Sump Depth ---    5.46"

Maximum Stroke ---   3.62"

Oil Filter Location ---    Stock

Sump Oil Capacity ---   5.7 Quarts

Total Oil Capacity ---   6.2 Quarts with Stock Filter

Baffled ---   Yes

Windage Tray ---   Not Included

Includes:

Oil Pan Gasket

Sump Baffle

Oil Pickup Tube

Drain Plug

Oil Filter Stud

Oil Passage Cover

Mounting Hardware

Designed for use with GM #12558253 windage tray, which must be altered to add clearance for the pick-up tube

Ideal for Camaro/Firebird ('67-'69), Nova/Apollo/Ventura/Omega ('82-'92), GM A-body ('64-'72), G-body ('78-'87), and F-body ('82-'92)

Engine position (fore/aft or height) may need to be adjusted for clearance, depending on application

Fits most LS engines, except LS7 or LS9 dry sump applications

Requires the use of LS3 style dipstick and tube: GM #12669528 and 12625031,
