MONIPA 6 HP 2-Stroke Outboard Motor Tiller Shaft Inflatable Fishing Boat Marine Engine Water Cooling CDI System

Short shaft: 40cm

Dimension

Overall length 1040mm(40.9 in)

Overall width 872mm(34.3 in)

Overall height 332mm(13.1 in)

Transom height 44CM(17.3 in)

Performance

Full throttle operating range 5000-6000r/min

Maximum output 4.4KW/6HP

Idling speed ( in neutral) 1000±100 r/min

Gear positions Forward-neutral-reverse

Gear ratio 2.15(28/13)

Trim and tilt system: Manual tilt

Drive unit

Recommended fuel Regular unleaded gasoline

Integral fuel tank capacity 2.5L

Recommended engine oil 2-stroke outboard motor oil

Engine oil type Genuine or recommended 2str engine oil

Lubrication System Engine oil mixed gasoline

Engine oil mixing ratio Fuel 50: Engine oil 1

Gear oil quantity 195ml(6.6 fl.oz.)

Tightening torque for engine

Spark plug 25.0Nm(18.4 ft-lb) (2.55 kgf-m)

Engine oil drain bolt 18.0Nm(13.3 ft-lb) (1.84 kgf-m)

NOTE!!!!!!!!!!

Cylinder Scoring is a serious damage,which caused by improper use and will cost you a lot of money to repair the motor.

Don't do the following will avoid cylinder Scoring:

1, start the motor on bank

2, use the motor when it stop coming out of water Even if you want test the motor, it should be done in the river!

When there is no water coming out from the motor,please stop using it immediately,then check the impeller of Water pump or check if the water outlet has been blocked.

Note:Our machines are all without gear oil versions. Please add gear oil to the gears before using the motor and replace gear oil after the run-in period. (If you do not know how to handle this, please contact us). Our outboard motor doesn't with oil of gear, please prepare it by yourself.
