Saniflo Saniplus Macerator Pump + Round Bowl White, Toilet Tank

The Saniplus is a 1/2 HP pump system used to install a complete bathroom up to 15 feet below the sewer line, or even up to 150 feet away from a soil stack. It incorporates a macerating system which can handle human waste and toilet paper in residential applications. The blade is made out of a hardened stainless steel material which eliminates the need for any service or replacement.

• For full bathroom applications
• Discharge 15 Ft and/or 150 Ft
• Low inlets for easy installation

• Color: White
• Material: Stainless Steel
• Installation Type: Floor Mounted
• Max. horizontal discharge: 150 ft.
• Max. vertical discharge: 15 ft.
• Voltage: 120 V
• Includes: Up Flow Macerator Pump
• Frequency: 60 Hz
• Amperage: 4.5 Amps (Max)
• Motor: 0.5 HP oil-filled thermally protected motor
• Capacitor rating: 45 microfarad
• Operating temperature: 104°F (110°F Max.)
• Power cord length: 47-1/2 inches
• Noise level (measured at 3 ft.): 53 dBA (Lp)
• Discharge pipe diameter: 3 - 4 " or 1"
• Discharge rate at 15 ft.: 17 GPM
• Discharge rate at 3 ft.: 27 GPM
• Shut-off head: 30 ft.
• Normal running time: 10-12 s
• Capacity: 3 gallons / 11.4 liters
• Inlets diameters: 2" (sides)
• Ventilation diameter: 1-1/2"vent (top)
• Type of activation: Membrane/microswitch
• Shower/bath base height: 6" min
